2-16
Chapter 2: Installation and Wiring
NOTE
User's Manual Pub. 0300241-02 Rev. A

2.9.1 Perform the Startup Procedure

1. Apply power to the controller system.
2. Download your program, which contains the module configuration
settings, to the controller.
3. Put the controller in Run mode. During a normal start-up, the module
status LED turns on.
If the module status LED does not turn on, cycle power. If the condition
persists, contact your local distributor or Spectrum Controls for assistance.
2.9.2 Monitor Module Status to Check if the Module
is Operating Correctly
Module and channel configuration errors are reported to the controller. These
errors are typically reported in the controller's I/O status file. Channel status data
is also reported in the module's input data table, so these bits can be used in your
control program to flag a channel error.
