Chapter 2
Installation and Wiring
This chapter covers:
Tools and Equipment

Compliance to European Union directives

Power requirements
General considerations
Mounting
You need the following tools and equipment:
Medium blade or cross-head screwdriver
RTD or direct resistance input device
Shielded, twisted-pair cable for wiring (Belden™ 9501 or equivalent)
Controller (for example, a MicroLogix™ 1500 or CompactLogix™
controller)
Programming device and software (for example, RSLogix 500™ or
RSLogix 5000™)
This product is approved for installation within the European Union and EEA
regions. It has been designed and tested to meet the following directives.

2.3.1 EMC Directive

The 1769sc-IR6I module is tested to meet Council Directive 2014/30/EU
Electromagnetic Compatibility (EMC) and the following standards, in whole or
in part, documented in a technical construction file:
EN 61131-2 Programable controllers, Part 2 - Equipment requirements
and tests.
EN 61000-6-2 Electromagnetic compatibility (EMC) – Part 6-2: Generic
standards – Immunity standard for industrial environments.
EN 61000-6-4 Electromagnetic compatibility (EMC) – Part 6-4: Generic
standards – Emission standard for industrial environments.
This product is intended for use in an industrial environment.
