Appendix C: Configuring the IR6I for CompactLogix Controllers in RSLogix 5000
Configuring a
1769sc-IR6I
Isolated
RTD/resistance
Module
Configuration Data: Local:s:C
Where s is the slot number assigned to the I/O modules in the Generic Profiles.
In order to configure an I/O module, you must open up the configuration tag for
that module by clicking on the plus sign to the left of its configuration tag in the
Controller Tag data base.
To configure the 1769sc-IR6I module in slot 1, click on the plus sign left of
Local:1:C. Configuration data is entered under the Local:1:C.Data tag. Click the
plus sign to the left of Local:1:C.Data to reveal the 13 integer data words where
configuration data may be entered for the 1769sc-IR6I module. The tag
addresses for these 13 words are Local:1:C.Data[0] through Local:1:C.Data[12].
Only the first 13 words of the configuration file apply.
The first 6 configuration words, 0 through 5, apply to 1769sc-IR6I channels 0
through 5 respectively. All 6 words configure the same parameters for the 6
different channels. The seventh configuration word is unused. The following
table shows the various parameters to configure in each channel configuration
word. For a complete description of each of these parameters and the choices
available for each of them, see Configuration Data File on page 3-2.
Bit(s) (Words 0 to 5) Parameter
0 to 2
3
4
5 to 6
7
8 to 11
12 to 14
15
Once you have entered your configuration selections for each channel, enter your
program logic, save your project, and download it to your CompactLogix
Controller. Your module configuration data is downloaded to your I/O modules
at this time.
Filter Frequency
Not Used
Cyclic Lead Compensation
Open Circuit Condition
Temperature Units
Input Type
Data Format
Enable Channel
User's Manual Pub. 0300241-02 Rev. A
C-5
