A-2
Appendix A: Specifications
Storage Temperature
Operating
Temperature
Operating Humidity
Operating Altitude
Vibration
Shock
Unpackaged (Non-
operating)
Unpackaged
(Operating)
Agency Certification
Hazardous
Environment Class
Radiated and
Conducted Emissions
Electrical /EMC:
ESD Immunity
(IEC61000-4-2)
Radiated Immunity
(IEC61000-4-3)
Fast Transient Burst
(IEC61000-4-4)
Surge Immunity
(IEC61000-4-5)
Conducted Immunity
(IEC61000-4-6)
Fault detection
CMRR
NMRR
Input Impedance
Calibrated Accuracy
Accuracy is dependent on the ADC frequency selection, data format, and input noise.
7
User's Manual Pub. 0300241-02 Rev. A
-40 °C to +85 °C (-40 °F to +185 °F)
0 °C to +60 °C (32 °F to +140 °F)
5% to 95% non-condensing
2000 meters (6561 feet)
5 g at 10–500 Hz
½ Sine Shockwave 20 g at 9 ms, 3 shock/axis
½ Sine Shockwave 30 g at 11 ms, 1 shock/axis
C-UL certified (under CSA C22.2 No. 142)
UL 508 listed
CE compliant for all applicable directives
Class I, Division 2, Hazardous Location, Groups A, B, C, D
(ISA 12.12.01, C-UL under CSA C22.2 No. 213)
Operating Temperature Code T5
IEC61000-6-4 FCC Part 15B Class A
The module has passed testing at the following levels:
4 kV contact, 8 kV air
10 V/m, 80 to 1000 MHz, 80% amplitude modulation, 900 MHz and 1890
MHz 100% amplitude modulation
4 kV
2 kV Line - Line, 4 kV Line - GND
10 V, 0.15 to 80 MHz
Open circuit detection, over-range and under-range error bits.
Open circuit detection time is equal to the channel update time.
Greater than 100 dB at 50 Hz (4.17 Hz, 10 Hz, 16.7 Hz filter)
Greater than 100 dB at 60 Hz (4.17 Hz, 10 Hz, 19.6 Hz filter)
Greater than 65 dB at 50 Hz (4.17 Hz, 10 Hz, 16.7 Hz filter)
Greater than 65 dB at 60 Hz (4.17 Hz, 10 Hz, 19.6 Hz filter)
Greater than 500 kΩs
7
