NOTE
Section 4.7
Error Codes
Hex
Error Type
Equivalent
No Error X000
General X200
Common
Hardware
X201
Error
X300
X301
X30B
Hardware
X30C
Specific
X30D
Error
X30E
X30F
X310
X400
Module
X401
Specific
Configuration
X402
Error
X403
X404
Chapter 5: Diagnostics and Troubleshooting
If no errors are present in the module error field, the extended error
information field is set to zero.

Hardware Errors

General or module-specific hardware errors are indicated by module error code
001. See the Extended Error Codes table.

Configuration Errors

If you set the fields in the configuration file to invalid or unsupported values, the
module generates a critical error.
The Extended Error Codes tabke lists the possible module-specific configuration
error codes defined for the modules.
The table below explains the extended error codes.
Table 4-3 Extended Error Codes
Module
Extended Error
Error
Information Code
Code
(Binary)
(Binary)
000 0 0000 0000
001 0 0000 0000
001 0 0000 0001
001 1 0000 0000
001 1 0000 0001
001 1 0000 1011
001 1 0000 1100
001 1 0000 1101
001 1 0000 1110
001 1 0000 1111
001 1 0001 0000
010 0 0000 0000
010 0 0000 0001
010 0 0000 0010
010 0 0000 0011
010 0 0000 0100
Error Description
No Errors
General Hardware error; no additional
information
Power-up reset state
General Hardware Error (ASIC)
H/W ROM Error (Calibration Error)
Channel 0 ADC Error
Channel 1 ADC Error
Channel 2 ADC Error
Channel 3 ADC Error
Channel 4 ADC Error
Channel 5 ADC Error
General Config Error: no additional
information
invalid input type selected ch0
invalid input type selected ch1
invalid input type selected ch2
invalid input type selected ch3
User's Manual Pub. 0300244-02 Rev. A
4-5
