3-10
Chapter 3:
CCW Var Index
Bit
_IO_Xx_ST_40
8
_IO_Xx_ST_46:41 14:9
_IO_Xx_ST_47
15

Module Error

Fault Code
Extended Fault Code
0×301
0×F29z*
3
0×302
z indicates the slot number of the expansion I/O. If z=0, then the slot number cannot be identified
3
User's Manual Pub. 0300309-01 Rev. B
Configuring the Micro800 Expansion I/O 2085-OX32-SC Using CCW
Name
Description
Invalid Serial Number Data
The stored serial number checksum is corrupt or invalid.
SN
The module must be factory calibrated before it will operate
normally.
Not Used
Variables marked as Not Used remain disabled.
Module Fault
If one of the above three status variables is set to enabled, this
MF
variable will be enabled as a global Module Fault. All
channel outputs will be turned off for safety.
Channel Control (CCW Var: _IO_Xx_DO_31:00)
You use the Channel control variable to enable or disable each channel output.
The variable is located on the CCW Global Variables tab in visual checkbox
format and in _IO_Xx_DO_yy string format, where:
x represents the expansion slot number 1...3 for Micro850 controller and
slot number 1...8 for Micro870 controller
yy represents the channel number 00...31.
The module notifies the host PLC of critical and non-critical errors. The
Micro850 or Micro870 PLCs can generate a series of 0xF2xy errors specifically
for the installed module.
If any of the following faults occur, refer to the Configuration table to use
appropriate values:

3.6.1 Module Specific Hardware Errors

If you attempt to trigger or cause a hardware error, the CCW software generates a
high-level hardware fault with an extended code for details. The connection
status is faulted and disconnected. The follow table contains some examples of
module-specific hardware faults that can be detected and shown in CCW:
Error Description
MCU board power brownout
FPGA communications error
The extended fault code is only available when connecting with the Micro850
Series A & B PLCs and Micro870 Series A PLC with its PLC firmware revision
11.011 and above. The extended fault code will show as 0×0000 if connecting
with the Micro850 Series A PLC and its PLC firmware revision 10.011 and
under.
