DIMM0
512MB
1G
1G

Installation and Removal

To install a SO-DIMM, line up the notch in the SO-DIMM with the land in the
socket and insert the device into the socket at a 30° angle. When fully inserted
in the socket, press down to lock the retention clips into place. To remove an
SO-DIMM, release the retention clips on each end of the SO-DIMM and the
device will flip to a 30° angle.
Figure 3-21: Installing or Removing a SO-DIMM (left)
Workstation 5A Setup Guide - Fourth Edition
DIMM1 Total
-- 512MB
--
1G
Figure 3-20: SO-DIMM Configuration
Operating System
Windows Embedded CE
6.0, R3
1G POSReady 2009
2G POSReady 2009
What's Inside?
Installing Options
3-27
