Sata Win32 Factory Restore - Oracle MICROS Workstation 5A Setup Manual

Installing and Operating the Workstation 5A
Workstation 5A Recovery
• The workstation restarts, and boots from the Recovery CF. A series of
prompts appear, including 'Loading RAM Disk Image', followed by a
'Starting Windows Pre-boot Environment'.
• After a brief time, a Command Window appears, followed by 'Loading
Recovery Script...' Ghost32 starts.
• If the image specified in the RECOV.DAT file is present, the transfer
starts.
•
• When the image transfer is complete, the boot order is restored to start
from the original USB Hard Drive, and the workstation restarts.

SATA Win32 Factory Restore

Use this selection if the workstation contains an optional SATA Disk Drive.
1. With a USB Keyboard attached and the POSReady 2009 Recovery CF
installed in the CF Daughter Card, power-up the workstation with the
power button.
2. When the Blue Splash Screen appears, press the [Del] key to enter the
System Configuration Utility.
3. Navigate to the ODM Special Configuration Menu, and set the 'SATA
Win32 Factory Restore' to [Enabled].
4. Select the Exit tab then Save Settings and Restart, [Enter], and [Y] to
restart the workstation.
•
•
•
•
4-34
If the path and image name are not specified correctly, an error box
appears, stating "Image file not found!" See page 4-36 for more
information.
The workstation restarts, and boots from the Recovery CF. A series
of prompts appear, including 'Loading RAM Disk Image', followed
by a 'Starting Windows Pre-boot Environment'.
After a brief time, a Command Window appears, followed by
'Loading Recovery Script...' Ghost32 starts.
If the image specified in the RECOV.DAT file is present, the
transfer starts.
• If the path and image name are not specified correctly, an error
box appears, stating "Image file not found!" See page 4-36 for
more information.
When the image transfer is complete, the workstation restarts the
restores the original boot order.
Workstation 5A Setup Guide - Fourth Edition
