Booting to POSReady 2009

After the BIOS Splash Screen clears, the Windows XP start up screen and
progress bar appears.
After the desktop appears, the API loads and the Operator LED stops
blinking and turns solid white.
Unlike Windows Embedded CE 6.0, on new workstation, the Client
Application Loader (CAL) WIN32 is not pre-installed. It can be installed
by tapping the desktop icon.
Turning the Workstation from
• For Windows Embedded CE 6.0, press and hold the power button until the
Operator LED changes from solid White to OFF, then release it. This takes
about 4 seconds.
• For POSReady 2009, do not hold the power button down until the
workstation shuts down. Tap the power button and 'Shut Down Windows'
dialog box appears. Select 'Shut Down' from the pull-down menu, and tap
[OK] to shut down the unit. If the Shut Down Windows' dialog box does
not appear, Tap Start -> Shut Down -> Shut Down, then [OK].
Starting the Windows CE Workstation for the First Time
When a workstation with Windows CE is powered up for the first time, the
CAL automatically starts through a registry setting and displays a password
screen. Continue to the next page for more details about using the CAL on
Windows Embedded CE 6.0 R3.
When a workstation with a WIN32 operating system is installed, the user must
install the WIN32 CAL client.
Using the Client Application Loader (CAL) on Windows CE
1. If the unit is direct from the factory, a touchscreen calibration utility will
appear. See page 4-25.
2. CAL displays the password screen shown in Figure 4-13, below under the
following conditions.
• The workstation is new 'out-of-the-box', or the Wipe CF utility has
been used to delete the persistent registry and or erase the CF Card.
Workstation 5A Setup Guide - Fourth Edition
Installing and Operating the Workstation 5A
to
ON NOPOWER
Operation
4-17
