Appendix B
Connector and Cable Diagrams
On the pages that follow, you will find diagrams of the Workstation 5A I/O
Panel connectors, system board connectors, and commonly used hook-up
cables. A description of how each cable or connector is used is provided.
In this appendix
IO Panel Connectors .................................................................................... B-2
System Board Connectors............................................................................B-6
Hook-up Cables ...........................................................................................B-7
Workstation 5A Setup Guide - Fourth Edition
