Calibrating The Touchscreen

Calibrating the touchscreen is the process of aligning the touchscreen glass
with the underlying video display.

When to Calibrate the Touchscreen

• When installing a new workstation.
• Any time the cursor does not follow the movement of your finger, or does
not reach the edges of the touchscreen.
• If the LCD panel or touchscreen glass have been replaced.
• After performing a workstation Personality Swap (Windows CE Only).
Tips for Calibrating the Touchscreen
• Perform the calibration procedure in the position (sitting or standing) that
the workstation is normally used.
• Face the Touchscreen directly. If the workstation is on a stand, adjust it to
the optimum viewing angle.
Windows Embedded CE 6.0
1. From the desktop, press Start -> Settings -> Control Panel and tap the
'EloTouch icon. Touch or click the 'Calibrate' button to proceed.
• If you do not touch the screen within twenty seconds, the calibration
utility will shut down and retain the previous calibration values.
2. To begin, touch the center of the cross-hair that appear on the screen.
Continue to touch each target at the positions indicated - upper right, and
lower right.
• Make sure the cursor follows you finger at each corner of the screen.
Press [Accept] to compete the procedure and exit the utility.
POSReady 2009
Touch the desktop icon to start the touchscreen calibration.
