Appendix B - Technical Specifications
Appendix B
Dimensions (L x W x H):
Weight:
Physical Security:
System Interface (W x H):
Card issuance times:
Card output bin capacity:
Card rejection bin capacity:
Duty cycle:
Power Requirements:
Power Consumption:
Data Ports:
The EC2000 is designed to use card stock that meets the specifications listed ISO/IEC 7810 and
IEC/ISO 7811-1 through 7811-6.
Card Stock Hopper Capacity:
Accepted card types:
Accepted card sizes:
Acceptable card thickness:
ExpressCard 2000| Instant Issuance Card Personalization System | User Installation and Operation Manual
Page 81
Technical Specifications
Physical Characteristics
24.7 in. x 26.8 in. x 15.1 in.
(627 mm x 680 mm x 384 mm)
Device: 88 lbs. (39.9 kg)
Accessories: 3.8 lbs (1.7 kg)
⅜" chassis anchor hole for desktop / counter mounting
Ring-shaped security anchor
4.5 in. x 3.75 in. (114 mm x 95 mm) touchscreen
Operational Characteristics
Card-to-card cycle measurements. Times include 2-sided image
printing, front overlay, embossing, rear indenting, and foil tipping.
~104 seconds for embossing and tipping pre-lithographed stock
~132 seconds for 2-sided monochrome images
~146 seconds for color front / monochrome back images
~163 seconds for 2-sided color images
10 cards (at 30 mil thickness)
20 cards (at 30 mil thickness)
50 cards per day (15,000 cards per year)
Electrical Characteristics
100 VAC to 240 VAC at 50 or 60 Hz (Auto-adjusting)
Sleep: 15 Watts
Idle: 60 Watts
Peak: 200 Watts
Ethernet 100 base-T (external)
USB 2.0 (internal)
Card Stock Characteristics
700 stock cards total (100 cards x 7 card stock hoppers)
PVC, Optical memory cards with PVC finish
Polyester cards with polished PVC finish (monochrome only)
CR80 (3.370"L x 2.125"W / 85.6 mm L x 54 mm W)
0.020" (20 mil / 0.508 mm) to 0.050" (50 mil/ 1.27 mm)
50 mil cards can be used for single-sided printing only.
Max. embossed relief height for returned cards is 0.019 in. (0.48 mm)
