MAKING MODERN LIVING POSSIBLE
Quick Guide
®
VLT
Compressor Drive CDS 803
www.danfoss.com/drives

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VLT CDS 803 and is the answer not in the manual?

Questions and answers

Related Manuals for Danfoss VLT CDS 803

Summary of Contents for Danfoss VLT CDS 803

  • Page 1 MAKING MODERN LIVING POSSIBLE Quick Guide ® Compressor Drive CDS 803 www.danfoss.com/drives...

  • Page 3: Table Of Contents

    1.7.2 Mains Supply 3x380-480 V AC 1.8 Special Conditions 1.8.1 Derating for Ambient Temperature and Switching Frequency 1.8.2 Derating for Low Air Pressure ® 1.9 Options for VLT Compressor Drive CDS 803 MG18M102 Danfoss A/S © Rev. 09/2014 All rights reserved.

  • Page 4: Quick Guide

    See also Danfoss Application Note on RCD, MN90G. WARNING Protective earthing of the frequency converter and the...

  • Page 5: Approvals

    Table 1.3 H3-H4, 400 V Cooling capacity 200 V IP20 RFI switch Enclosure 4 TR/VZH028 Illustration 1.1 IP20 5 TR/VZH035 6.5 TR/VZH044 CAUTION Table 1.4 H4-H5, 200 V If reinserted, only use M3x12 screw. MG18M102 Danfoss A/S © Rev. 09/2014 All rights reserved.

  • Page 6: Side-By-Side Installation

    The dimensions are only for the physical units, but when installing in an application it is necessary to add space for free air passage both above and below the units. The amount of space for free air passage is listed in Table 1.5. Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102...

  • Page 7: Connecting To Mains And Compressor

    IP20 IP20 IP20 Table 1.7 Enclosure H3-H5 1.3.6 Connecting to Mains and Compressor The frequency converter is designed to operate Danfoss VZH Compressors. For maximum cross-section on wires see chapter 1.7 General Specifications. • Use a shielded/armored compressor cable to...
  • Page 8 Illustration 1.3 Mount the 2 screws in the mounting plate, slide it into place and tighten fully. MOTOR Illustration 1.6 Mount mains plug and tighten wires. Illustration 1.4 H3-H5 Frame Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102...

  • Page 9: Fuses

    Short circuit protection Danfoss recommends using the fuses listed in Table 1.9 to protect service personnel or equipment in case of an internal failure in the unit or short-circuit on DC-link. The frequency converter provides full short circuit protection in case of a short- circuit on the compressor.

  • Page 10: Emc-Correct Electrical Installation

    Control cables Motor cable Min. 200mm between control Mains-supply cable, mains cable and between mains motor cable Motor, 3 phases and Reinforced protective earth Protective earth Illustration 1.8 EMC-correct Electrical Installation Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102...

  • Page 11: Control Terminals

    Set the functions of digital input 18, 19 and 27 in 5-00 Digital Input Mode (PNP is default value). Set the function of digital input 29 in 5-03 Digital Input 29 Mode (PNP is default value). MG18M102 Danfoss A/S © Rev. 09/2014 All rights reserved.
  • Page 12 Interface 29 (DIGI IN) (P RS-485) 68 24 V (NPN) O V (PNP) Do not connect shield to 61 (Com RS-485 ) 61 (PNP)-Source (NPN)-Sink Illustration 1.11 Basic Wiring Schematic Drawing Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102...

  • Page 13: Programming

    [Off/Reset]: Stops the compressor (Off). If in alarm mode, the alarm is reset. [Auto On]: Frequency converter is controlled either via control terminals or serial communication. Table 1.12 Legend to Illustration 1.12 MG18M102 Danfoss A/S © Rev. 09/2014 All rights reserved.

  • Page 14: The Start-Up Wizard

    Quick Menu. Press [OK] to start the wizard. Press [Back] to return to the status screen. Press OK to start Wizard Push Back to skip it Setup 1 Illustration 1.14 Start-up/Quit Wizard Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102...
  • Page 15 Setup 1 0.0 Hz 0.0 kW Setup 1 Status Quick Main Menu Menu Menu Com. Warn. Alarm Auto Hand Reset Status Screen The Wizard can always be reentered via the Quick Menu! MG18M102 Danfoss A/S © Rev. 09/2014 All rights reserved.
  • Page 16 0.05-3600.0 s 30.00 s Ramp-up time from 0 to 1-25 Motor Nominal Speed. 3-42 Ramp 1 Ramp Down Time 0.05-3600.0 s 30.00 s Ramp down time from rated motor speed to Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102...
  • Page 17 Select the baud rate for the RS-485 port. 4800 Baud *[2] 9600 Baud [3] 19200 Baud 4] 38400 Baud 5] 57600 Baud [6] 76800 Baud [7] 115200 Baud Table 1.13 Open Loop Applications Set-up MG18M102 Danfoss A/S © Rev. 09/2014 All rights reserved.
  • Page 18 28-11 Low Speed Running Time 1-1400 min 20 min Enter the low speed running time. 28-13 Boost Duration 10-3600 s 60 s Enter the boost duration for the oil return. Table 1.14 Compressor Function Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102...
  • Page 19 6-25 Terminal 54 High Ref./Feedb. 50.000 20-00 Feedback 1 Source 0.00 No function 20-81 Normal/Inverse Control Normal 8-01 Control Site Digital and ctrl.word 8-30 Protocol 8-32 Baud Rate 9600 Illustration 1.17 Closed Loop Wizard MG18M102 Danfoss A/S © Rev. 09/2014 All rights reserved.
  • Page 20 0.05-3600.0 s 30.00 s Ramp up time from 0 to 1-25 Motor Nominal Speed. 3-42 Ramp 1 Ramp Down Time 0.05-3600.0 s 30.00 s Ramp-down time from rated motor speed to Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102...
  • Page 21 6-21 Terminal 54 High Voltage. 8-01 Control Site [0] Digital and ctrl.word Select if digital, bus, or a combination of both [1] Digital only should control the frequency converter. [2] Controlword only MG18M102 Danfoss A/S © Rev. 09/2014 All rights reserved.
  • Page 22 Press [ ] to change the value of a parameter setting. Press [OK] to accept the change. Press either [Back] twice to enter Status, or press [Menu] once to enter Main Menu. Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102...

  • Page 23: Main Menu Structure

    Quick Guide Quick Guide MG18M102 Danfoss A/S © Rev. 09/2014 All rights reserved.
  • Page 24 Quick Guide Quick Guide Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102...

  • Page 25: Acoustic Noise Or Vibration

    Control Voltage Fault 24 V DC may be overloaded. VDD1 supply low Control voltage low. Contact the local Danfoss supplier The speed is below the specified limit in 1-87 Compressor Min. Speed for Trip [Hz]. AMA internal Contact the local Danfoss supplier.

  • Page 26: General Specifications

    (Only on 400 V 30-90 kW units). Contact the local Danfoss supplier The frequency converter has a new type code (Only on 400 V New Typecode 30-90 kW units). Contact the local Danfoss supplier. Table 1.16 Warnings and Alarms 1.7 General Specifications 1.7.1 Mains Supply 3x200-240 V AC...

  • Page 27: Mains Supply 3X380-480 V Ac

    Estimated power loss [W], 104/131 159/198 248/274 best case/typical Weight enclosure protection IP20 [kg] Efficiency [%], 98.4/98.0 98.2/97.8 98.1/97.9 best case/typical Table 1.18 3x380-480 V AC 1) At rated load conditions MG18M102 Danfoss A/S © Rev. 09/2014 All rights reserved.
  • Page 28 The unit is suitable for use on a circuit capable of delivering not more than 100000 RMS symmetrical Amperes, 240/480 V maximum. Compressor output (U, V, W) Output voltage 0-100% of supply voltage Output frequency 0-200 Hz (VVC ), 0-400 Hz (u/f) Switching on output Unlimited Ramp times 0.05-3600 s Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102...
  • Page 29 Voltage level at digital output 17 V Maximum output current at digital output 20 mA Maximum load at digital output 1 kΩ 1) Terminals 42 and 45 can also be programmed as analog output. MG18M102 Danfoss A/S © Rev. 09/2014 All rights reserved.
  • Page 30 EN/IEC 61800-5-1, UL 508C EMC standards, Emission EN 61800-3, EN 61000-6-3/4, EN 55011, IEC 61800-3 EMC standards, EN 61800-3, EN 61000-3-12, EN 61000-6-1/2, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN Immunity 61000-4-5, EN 61000-4-6 Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102...

  • Page 31: Special Conditions

    1.8.2 Derating for Low Air Pressure The cooling capability of air is decreased at low air pressure. For altitudes above 2000 m, contact Danfoss regarding PELV. Below 1000 m altitude no derating is necessary, but above 1000 m the ambient temperature or the maximum output current should be decreased.
  • Page 32 Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products already on order provided that such alterations can be made without subsequential changes being necessary in specifications already agreed. All trademarks in this material are property of the respective companies.
