How to Order a Drive

13 How to Order a Drive

13.1 Drive Configurator

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
F C -
Table 13.1 Type Code String
Product groups
Drive series
Generation code
Power rating
Phases
Mains Voltage
Enclosure
Enclosure type
Enclosure class
Control supply voltage
Hardware configuration
RFI filter/Low Harmonic Drive/12-
pulse
Brake
Display (LCP)
Coating PCB
Mains option
Adaptation A
Adaptation B
Software release
Software language
A option
B options
C0 options, MCO
C1 options
C option software
D options
Table 13.2 Type Code Example for Ordering a Drive
MG22B102
Design Guide
T
1–3
4–6
7
8–10
11
12
13–15
16–23
16–17
18
19
20
21
22
23
24–27
28
29–30
31–32
33–34
35
36–37
38–39
Danfoss A/S © 05/2017 All rights reserved.
21 22 23 24 25 26 27 28 29 30
X X S X X X X A
Configure the correct drive for the proper application by
using the internet-based drive configurator. The drive
configurator is found on the global internet site:
www.danfoss.com/drives. The configurator creates a type
code string and an 8-digit sales number, which can be
delivered to the local sales office. It is also possible to
build a project list with several products and send it to a
Danfoss sales representative.
An example of a type code string is:
FC-202N355T5E20H4BGCXXXSXXXXA0BXCXXXXD0
The meaning of the characters in the string is defined in
Table 13.3. In the example above, a PROFIBUS DP-V1 and a
24 V back-up option is built-in.
Drives are delivered automatically with a language package
relevant to the region from which they are ordered. Four
regional language packages cover the following languages:
Language package 1
English, German, French, Danish, Dutch, Spanish, Swedish,
Italian, and Finnish.
Language package 2
English, German, Chinese, Korean, Japanese, Thai,
Traditional Chinese, and Bahasa Indonesian.
Language package 3
English, German, Slovenian, Bulgarian, Serbian, Romanian,
Hungarian, Czech, and Russian.
Language package 4
English, German, Spanish, English US, Greek, Brazilian
Portuguese, Turkish, and Polish.
To order drives with a different language package, contact
the local Danfoss sales office.
31 32 33 34 35 36 37 38 39
B C D
