General Specifications
Control card, 24 V DC output
Terminal number
Maximum load
Relay output
Programmable relay output
Relay 01 and 02
Maximum terminal load (AC-1)
Maximum terminal load (AC-15)
Maximum terminal load (DC-1)
Maximum terminal load (DC-13)
Maximum terminal load (AC-1)
Maximum terminal load (AC-15)
Maximum terminal load (DC-1)
Minimum terminal load on 01–03 (NC), 01–02 (NO)
Environment according to EN 60664-1
1) IEC 60947 parts 4 and 5.
Control card, 10 V DC output
Terminal number
Output voltage
Maximum load
Surroundings
Enclosure
Enclosure kit available
Vibration test
Maximum relative humidity
Aggressive environment (IEC 60721-3-3), coated (standard)
Test method according to IEC 60068-2-43 H2S (10 days)
Ambient temperature
Derating for high ambient temperature, see chapter 8.4 Derating according to Ambient Temperature and Switching Frequency.
Minimum ambient temperature during full-scale operation
Minimum ambient temperature at reduced performance
Temperature during storage/transport
Maximum altitude above sea level without derating
Maximum altitude above sea level with derating
Derating for high altitude, see chapter 8.4 Derating according to Ambient Temperature and Switching Frequency.
Safety standards
EMC standards, Emission
EMC standards,
Immunity
MG18N202
Design Guide
1)
on 01–02/04–05 (NO) (Resistive load)
1)
on 01–02/04–05 (NO) (Inductive load @ cosφ 0.4)
1) on 01–02/04–05 (NO) (Resistive load)
1)
on 01–02/04–05 (NO) (Inductive load)
1)
on 01–03/04–06 (NC) (Resistive load)
1)
on 01–03/04–06 (NC) (Inductive load @ cosφ 0.4)
1)
on 01–03/04–06 (NC) (Resistive load)
5–95% (IEC 60721-3-3; Class 3K3 (non-condensing) during operation
EN 61800-3, EN 61000-3-12, EN 61000-6-1/2, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN
Danfoss A/S © 12/2015 All rights reserved.
01–03 (NC), 01–02 (NO), 04–06 (NC), 04–05 (NO)
24 V DC 10 mA, 24 V AC 20 mA
Overvoltage category III/pollution degree 2
-30 to +65/70 °C (-22 to +149/158 °F)
EN/IEC 61800-5-1, UL 508C
EN 61800-3, EN 61000-6-3/4, EN 55011, IEC 61800-3
61000-4-5, EN 61000-4-6
12
80 mA
2
250 V AC, 3 A
250 V AC, 0.2 A
30 V DC, 2 A
24 V DC, 0.1 A
250 V AC, 3 A
250 V AC, 0.2 A
30 V DC, 2 A
50
8 8
10.5 V ±0.5 V
25 mA
IP20
IP21, TYPE 1
1.0 g
Class 3C3
50 °C (122 °F)
0 °C (32 °F)
-20 °C (-4 °F)
1000 m (3280 ft)
3000 m (9843 ft)
