How to Program
Closed-loop quick guide
Parameter
Parameter 0-01 Language
Parameter 0-06 GridType
Parameter 0-60 Main Menu Password
Parameter 1-00 Configuration Mode
Parameter 1-13 Compressor Selection
Parameter 3-02 Minimum Reference
Parameter 3-03 Maximum Reference
Parameter 3-10 Preset Reference
Parameter 3-15 Reference 1 Source
Parameter 3-41 Ramp 1 Ramp Up
Time
Parameter 3-42 Ramp 1 Ramp Down
Time
MG18N202
Design Guide
Option
[0] English
[1] Deutsch
[2] Francais
[3] Dansk
[4] Spanish
[5] Italiano
[28] Bras.port
[0] 200–240 V/50 Hz/IT-grid
[1] 200–240 V/50 Hz/Delta
[2] 200–240 V/50 Hz
[10] 380–440 V/50 Hz/IT-grid
[11] 380–440 V/50 Hz/Delta
[12] 380–440 V/50 Hz
[20] 440–480 V/50 Hz/IT-grid
[21] 440–480 V/50 Hz/Delta
[22] 440–480 V/50 Hz
[30] 525–600 V/50 Hz/IT-grid
[31] 525–600 V/50 Hz/Delta
[32] 525–600 V/50 Hz
[100] 200–240 V/60 Hz/IT-grid
[101] 200–240 V/60 Hz/Delta
[102] 200–240 V/60 Hz
[110] 380–440 V/60 Hz/IT-grid
[111] 380–440 V/60 Hz/Delta
[112] 380–440 V/60 Hz
[120] 440–480 V/60 Hz/IT-grid
[121] 440–480 V/60 Hz/Delta
[122] 440–480 V/60 Hz
[130] 525–600 V/60 Hz/IT-grid
[131] 525–600 V/60 Hz/Delta
[132] 525–600 V/60 Hz
0–999
[0] Open loop
[3] Closed loop
[24] VZH028-R410A
[25] VZH035-R410A
[26] VZH044-R410A
-4999.0 – 200 Hz
0–200 Hz
-100 – 100 %
[0] No function
[1] Analog in 53
[2] Analog in 54
[7] Pulse input 29
[11] Local bus reference
0.05–3600.0 s
0.05–3600.0 s
Danfoss A/S © 12/2015 All rights reserved.
Default Function
0 Select the language for the display.
Size related Select the operating mode for restart after
reconnection of the frequency converter to
mains voltage after power-down.
0 Define the password for access to the LCP.
[0] Open loop Select closed loop.
Size related Select the used compressor.
0 Hz The minimum reference is the lowest value
obtainable by summing all references.
200 Hz The maximum reference is the highest
obtainable by summing all references.
0% Set up a fix setpoint in preset reference [0].
[1] Analog in 53 Select the input to be used for the reference
signal.
30.00 s Ramp-up time from 0 to parameter 1-25 Motor
Nominal Speed.
30.00 s Ramp-down time from nominal motor speed
to 0.
6 6
