How to Program
The Start-up quick guide for compressor functions
28-00 Short Cycle Protection
1
[1] Enabled
28-01 Interval between Starts
2
300 s
28-02 Minimum Run Time
3
60 s
28-10 Oil Return Management
4
[1] On
5 28-13 Boost Duration
60 s
Illustration 6.3 Compressor Function Quick Guide
Compressor function quick guide
Parameter
Parameter 28-00 Short Cycle
Protection
Parameter 28-01 Interval between
Starts
Parameter 28-02 Minimum Run Time
Parameter 28-10 Oil Return
Management
Parameter 28-13 Boost Duration
Table 6.5 Compressor Function
MG18N202
Design Guide
Option
[0] Disabled
[1] Enabled
0–3600 s
10–3600 s
[0] Off
[1] On
60–300 s
Danfoss A/S © 12/2015 All rights reserved.
Default Function
[1] Enabled Select if short cycle protection is to be used.
300 s Enter the minimum allowed time between
starts.
60 s Enter the minimum allowed time to run
before stop.
[1] On Select if oil return management is to be used.
60 s Enter the boost duration for the oil return.
