6
Product description
6. 1
Illustrations of the TS 5000 L passive leaf unit
6. 1 . 1
TS 5000 L passive leaf unit transom installation hinge side DIN right
Single side panel (for
continuous cover)
1
Rocker for integrated closing sequence control
2
Deflection pulley
6. 1 .2
TS 5000 L passive leaf unit transom installation hinge side DIN left
2
1
Rocker for integrated closing sequence control
2
Deflection pulley
8
Double side panel (for split cover)
1
Single side panel (for
continuous cover)
1
Double side panel (for split cover)
Powerturn F/R-IS/TS
2
