- Page 1 GEZE Perlan GB Mounting instructions AUT-NT Wood fitting 1-/2-leaf...
-
Page 2: Table Of Contents
GEZE Perlan AUT-NT Table of contents Symbols and means of representation ......................3 Warnings ..........................................3 Further symbols and means of representation .............................3 Product liability ................................3 Safety ...................................3 Intended use........................................3 Important safety instructions ..................................4 Safety-conscious working .....................................4 Inspection of the mounted system................................4 Additionally applicable documents ................................4... -
Page 3: Symbols And Means Of Representation
The PERLAN AUT-NT sliding door drive is designed for the automatic opening and closing of the sliding leaves. The PERLAN AUT-NT sliding door drive is suitable for use in dry rooms in private areas. The PERLAN AUT-NT sliding door drive may not be used at fire or smoke protection doors and in a hazardous (Ex) area. -
Page 4: Important Safety Instructions
The prescribed mounting, maintenance and repair work must be performed by properly trained personnel à authorised by GEZE. GEZE shall not be liable for injuries or damage resulting from unauthorised modification of the system. à GEZE shall not be liable if products from other manufacturers are used with GEZE equipment. -
Page 5: Transportation And Storage
Transportation and storage Transportation and storage CAUTION! Damage to the PERLAN AUT-NT sliding door drive through hard knocks and falls. Do not throw or let drop the PERLAN AUT-NT. CAUTION! Storage temperatures under –15°C and above +60°C can result in damage to the device. -
Page 6: Mounting Instructions
The technical company is responsible for the selection of the suitable mounting technology as well as the suit- able mounting material. The specified representations have to be adapted in accordance with the situation. The PERLAN AUT-NT roller-guided sliding door system is offered in the following variants: ��... - Page 7 GEZE Perlan AUT-NT Mounting Fasten the track (2) to the wall brackets (1) with screws and sliding blocks (3). 8. 1 .2 Wall mounting with concealed wall bracket Drill holes for the concealed wall bracket (4) in the wall. Screw the concealed wall bracket (4) onto the wall.
-
Page 8: Mounting The Drive Unit
Mounting GEZE Perlan AUT-NT 8. 1 .3 Ceiling mounting Drill holes into the ceiling. Use only countersunk screws to fasten the track to the ceiling. Use screws to screw the track (2) to the ceiling. Mounting the drive unit 8.2. 1 Mounting the drive unit for a 1-leaf system Slide the roller carriage (5) into the track (2). - Page 9 GEZE Perlan AUT-NT Mounting Slide the first buffer (6) and guide roller (7) into the track (2). Slide the second buffer (6) into the track (2). Slide the drive (8) into the track (2) until it stops. Tighten the clamping of the drive with an Allen...
- Page 10 Mounting GEZE Perlan AUT-NT 8.2.2 Mounting the drive unit for a 2-leaf system Slide the buffer (6) into the track (2). Slide the roller carriage (5) into the track (2). Slide the buffer (6) and guide roller (7) into the track (2).
-
Page 11: Hanging In The Door Leaves
GEZE Perlan AUT-NT Mounting Slide the buffer (6) into the track (2). Slide the drive (8) into the track (2) until it stops. Tighten the clamping of the drive with an Allen key Size 4 to 5 Nm. Hanging in the door leaves 8.3. - Page 12 Mounting GEZE Perlan AUT-NT Mount the carrier bracket (10) at a distance of 5.5 mm to the door leaf middle. �� �� ��� Hang in the door leaf and align to the wall. The bottom edge of the door leaf should have a...
-
Page 13: Positioning The Door Leaf To The Main Closing Edge
GEZE Perlan AUT-NT Mounting During mounting ensure that one carrier �� bracket (10) points to the wall and the other carrier bracket in the opposite direction. Mount the carrier bracket (10) at a distance of 5.5 mm to the door leaf middle. - Page 14 Mounting GEZE Perlan AUT-NT Slide the door leaf 200 mm towards the side closing edge. Tighten the clamping of the buffer (6) slightly with an Allen key. � Tighten the buffer (6) with 5 Nm. 8.4.2 Positioning the door leaf for a 2-leaf system to the main closing edge Slide the door leaf to the desired position.
-
Page 15: Positioning The Door Leaf To The Side Closing Edge
GEZE Perlan AUT-NT Mounting Slide the door leaf 200 mm towards the side closing edge. Tighten the clamping of the left- and right- � hand buffer (6) slightly with an Allen key. Tighten the left- and right-hand buffer (6) with 5 Nm. - Page 16 Mounting GEZE Perlan AUT-NT Slide the buffer (6) to the door leaf or the roller carriage. � Slide the door leaf 200 mm towards the main closing edge. Tighten the clamping of the buffer (6) slightly with an Allen key.
- Page 17 GEZE Perlan AUT-NT Mounting 8.5.2 Positioning the door leaf for a 2-leaf system to the side closing edge left Slide the door leaf to the desired position. Slide the buffer (6) to the door leaf or the roller carriage. �...
- Page 18 Mounting GEZE Perlan AUT-NT Slide the door leaf 200 mm towards the main closing edge. Tighten the clamping of the buffer (6) slightly with an Allen key. Clamp the buffer (6) with 5 Nm. � 8.5.3 Positioning the door leaf for a 2-leaf system to the side closing edge right...
-
Page 19: Mounting The Floor Guide
GEZE Perlan AUT-NT Mounting Slide the buffer (6) to the door leaf or the roller carriage. � Slide the door leaf 200 mm towards the side closing edge. � Tighten the clamping of the buffer (6) slightly with an Allen key. -
Page 20: Mounting The Toothed Belt
Mounting GEZE Perlan AUT-NT Mounting the toothed belt 8.7. 1 Mounting the toothed belt for a 1-leaf system Fasten the toothed belt beginning with the toothed belt lock Information on mounting the toothed belt lock: Wooden leaf: Mounting slip 10421-9-0931 à... - Page 21 GEZE Perlan AUT-NT Mounting Lay the toothed belt around the guide roller (16). �� Lay the two ends of the toothed belt together �� at the carrier plate (17). Connecting the toothed belt with the toothed belt lock Adapt the length of one toothed belt end and fasten it as tight as possible with the toothed ��...
- Page 22 Mounting GEZE Perlan AUT-NT 8.7.2 Mounting the toothed belt for a 2-leaf system Cutting the toothed belt to length Information on mounting the toothed belt lock: Wooden leaf: Mounting slip 10421-9-0931 à 1-leaf wooden leaf: Drawing 10421-EP-53 à 2-leaf wooden leaf: Drawing 10421-EP-55 à...
- Page 23 GEZE Perlan AUT-NT Mounting Connecting the toothed belt with the toothed belt lock Thread the second end of the toothed belt into the second toothed belt lock with the smooth side facing outwards. Knock in the locking pin (15). ��...
- Page 24 Mounting GEZE Perlan AUT-NT Lay together the second end at the carrier �� bracket (10). Adapt the length of one toothed belt end and fasten it as tight as possible with the toothed belt lock belonging to the carrier bracket.
- Page 25 GEZE Perlan AUT-NT Mounting Tighten the screw in the guide roller (16) with 5 Nm. ��...
- Page 26 Mounting GEZE Perlan AUT-NT...
-
Page 27: Ec-Declaration Of Conformity
GEZE Perlan AUT-NT EC-Declaration of Conformity EC-Declaration of Conformity... - Page 28 GEZE India Private Ltd. 2630 Taastrup Niederlassung West China MF2 & 3, Guindy Industrial Estate Tel. +45(0)46-323324 Nordsternstraße 65 GEZE Industries (Tianjin) Co., Ltd. Ekkattuthangal Fax +45(0)46-323326 45329 Essen Shuangchenzhong Road Chennai - 600 097 E-Mail: danmark.se@geze.com Tel. +49 (0) 201-83082-0...
