GEZE Powerturn IS/TS Installation Instructions Manual page 16

Converting the TS units
8.3. 1 Mounting the door closer unit
For the installation dimensions, see chapter 5.4.
TS 5000 L
TS 4000
Connection of the active and passive leaf drive:
Passive leaf (1)
16
1
1
2
1
Active leaf (2)
2
8 Nm
(2 ×)
2
8 Nm
(2 ×)
Powerturn F/R-IS/TS
2
8 Nm
(2 ×)
2
8 Nm
(2 ×)
