Types of installation
5.4

Fitting dimensions for the installation types

5.4. 1 Type of installation transom installation hinge side
1 Dimensional reference - Centre of hinge/Upper edge of door
2 Covered line-feed possible in the hatched area, e.g. Ø 20 mm for the mains connection or low-voltage
connection
3 Orientation arrow for precise positioning of the mounting plate
Fastening means
Drive fastening
TS attachment
Intermediate base plate attachment
Fastening standard roller guide rail
Powerturn
Fastening for the vertically adjustable
TS 5000 L guide rail
Space requirement and fastening
Standard roller guide rail Powerturn
5
50
4 Base top edge of door
5 Space requirement for sensors
6
Steel/aluminium doors
8 countersunk head screws M6 × 25 and riveting nuts M6 8 wood screws with
4 cylinder head screws M6 × 20 and riveting nuts M6
4 cylinder head screws M6 × 25 and riveting nuts M6
2 countersunk head screws M5 × 40 and riveting nuts M5 2 wood screws with
2 countersunk head screws M5 × 40 and riveting nuts M5 2 wood screws with
Sensor roller guide rail Powerturn
130
4
5
50
Timber doors
countersunk head Ø6 × 50
4 wood screws with cylinder
head Ø6 × 50
4 wood screws with cylinder
head Ø6 × 50
countersunk head Ø5 × 50
countersunk head Ø5 × 50
Guide rail TS 5000 L
66
Powerturn F/R-IS/TS
31
