Overview..................................6 Diagrams ..........................................6 Tools and aids ........................................6 Torques ..........................................6 Components and assembly groups ................................7 Bill of material VP-Kit Powerdrive PL-HT ..............................7 Pre-installation .................................8 Cutting the track to size ....................................8 Preparing the track ......................................8 Installing stop buffers .....................................9 Connecting the contact on the toothed belt lock (optional) ......................9 Installing the drive components ................................
Faults and corrective measures DCU1 / DCU1-2M Cable plan Single leaf Double leaf Safety analysis Automatic sliding doors Installation instructions Powerdrive PL-HT Powerdrive PL-HT Moving leaf Installation instructions These documents are subject to change. Use only the most recent version.
à in the installation variants / types of installation documented by GEZE à within the tested/approved area of application (climate / temperature / IP rating) Any other use is considered non-intended and will lead to the exclusion of all liability and warranty claims to GEZE. Safety notices à...
à Storage temperatures under –30 °C and above +60 °C can result in damage to the product. à Protect the product against humidity. à Dry, well ventilated, closed, weather-proof and UV-protected rooms are suitable as storage areas. Qualification Installation of the GEZE sliding door drive may only be carried out by experts authorised by GEZE.
About this document Powerdrive PL-HT KIT About this document These instructions describe the pre-installation of the Powerdrive PL-HT automatic sliding door drive. Overview 4. 1 Diagrams Drawing no. Type Designation 70722-9-0950 Drive drawing Powerdrive PL-HT drive 70506-2-0263 Production drawing Track made to measure for Powerdrive PL-HT...
The structure of the assembly groups can vary depending on the drive equipment or version. Precise details about positioning of the individual components can be found on the drive drawing (70722-9-0950). 1-leaf, right hand slide to open 1-leaf, left hand slide to open Bill of material VP-Kit Powerdrive PL-HT Transformer earthing Track Div. clear adhesive labels...
Pre-installation Powerdrive PL-HT KIT Pre-installation The up-to-date drive drawing is applicable for the pre-installation work to be carried out. All components must be identified and installed in accordance with the drive drawing. 5. 1 Cutting the track to size Check profiles for damage.
Powerdrive PL-HT KIT Pre-installation Installing stop buffers Push the stop buffers (1) onto the track from the left and right. Tighten the Allen screws (2) of the stop buffer slightly. Connecting the contact on the toothed belt lock (optional) Only insert the locking pin (1) in again after the cover has been set in place.
Pre-installation Powerdrive PL-HT KIT Installing the drive components The exact positioning of the components is given on the drive drawings. Illustrated: right hand slide to open, passage width 1065 mm Illustrated: left hand slide to open, passage width 1065 mm...
Powerdrive PL-HT KIT Pre-installation Connecting transformer and control unit Make sure that cables are routed and secured in such a way that they do not become jammed when the cover is positioned and cannot come into contact with moving components.
Pre-installation Powerdrive PL-HT KIT Connecting locking (optional) and control Plug in the locking cable (1) into the control unit. Lay cable to the locking mechanism, shorten if necessary, strip and attach insulated wire-end ferrules. Connect cable to locking mechanism (2) (see wiring diagram).
Powerdrive PL-HT KIT Pre-installation Checking the connection between rechargeable battery and control unit CAUTION! Danger of injury due to impact and crushing! When the rechargeable battery cable is plugged in, the door leaves can move unexpectedly. Make sure that the rechargeable battery cable is not plugged into the control unit.
Pre-installation Powerdrive PL-HT KIT 5. 1 0 Mounting the transformer earthing Slide the earthing rail (1) to its final position. Tighten 2 Allen screws (2) (torque Nm). Connect the earthing cable (3) from the trans- former to the device flat plug (4).
Powerdrive PL-HT KIT Pre-installation 5. 1 2 Production test WARNING Risk of fatal injury due to electric shock! The electrical system (230/115 V) may only be connected and disconnected by a professional electrician. Carry out mains connection and earth conductor test in accordance with VDE 0100 Part 610.
