Powerturn
EN Wiring diagram
Valid for variants:
Powerturn (1-leaf/2-leaf )
Powerturn F (1-leaf )
Powerturn F-IS (2-leaf )
Powerturn F/R (1-leaf )
Powerturn F/R-IS (2-leaf )
Powerturn F/R-IS/TS
156568-03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Powerturn and is the answer not in the manual?

Questions and answers

Related Manuals for GEZE Powerturn

Summary of Contents for GEZE Powerturn

  • Page 1 Powerturn EN Wiring diagram Valid for variants: Powerturn (1-leaf/2-leaf ) Powerturn F (1-leaf ) Powerturn F-IS (2-leaf ) Powerturn F/R (1-leaf ) Powerturn F/R-IS (2-leaf ) Powerturn F/R-IS/TS 156568-03...

  • Page 2: Table Of Contents

    Powerturn Contents Symbols and illustrations ..............................5 Validity .....................................5 Product liability ..................................5 Notes ....................................6 Important safety instructions ..................................6 Installation details ......................................6 Safety-conscious working .....................................6 Inspection of installed system ..................................7 Disposal of the door system ..................................7 Abbreviations ................................7 Electrical data ................................7 Supply terminals ..............................8 Safety sensor open and close ...........................
  • Page 3 Smoke switch control unit ..........................44 18.1 Integrated smoke switch Powerturn F/R .............................. 47 18.2 Powerturn F- IS/TS, F/R-IS/TS hold-open system – automatic active leaf, passive leaf with door closer and holding magnet ..........................................48 Mains connection ..............................50 19.1 Mounting plate with integrated feeder ..............................
  • Page 4 Powerturn Service menu ................................ 63 29.1 Service terminal ST220 ....................................63 29.2 Connecting service terminal ST220 ................................ 64 29.3 Service menu ST220 ..................................... 64 29.4 Display programme switch (DPS) ................................81 29.5 Service buttons S1 and S2 ..................................81 29.6 DPS service menu and service buttons S1/S2 with LEDs ........................

  • Page 5: Symbols And Illustrations

    Powerturn Symbols and illustrations Warning notices Warning notices are used in these instructions to warn you of property damage and personal injury. Always read and observe these warning notices. Observe all the measures that are marked with the warning symbol and warning word.

  • Page 6: Notes

    Keep these instructions. à Only specialists who are authorised by GEZE are permitted to carry out installation, commissioning and maintenance. à If unauthorised changes are made to the system, GEZE cannot be made liable in any way whatsoever for any resulting damages.

  • Page 7: Inspection Of Installed System

    Powerturn Abbreviations Inspection of installed system Measures for checking safety and prevention of crushing, impact, shearing or drawing-in spots. Check the function of the presence sensors and movement detectors. Check the protective earth connection to all metal parts that can be touched.

  • Page 8: Supply Terminals

    Supply terminals Powerturn Supply terminals Main switch DCU800 DCU801 (optional) DCU802 DCU800 RS485 passive leaf FREE DCU801 (optional) 24 V RSZ GND RSZ 24 V RSZ GND Second drive...
  • Page 9 Powerturn Supply terminals DCU802 N.N. 20 3 21 4 1 10 4 1 11 10 4 1 13 36 35 1 33 32 31 2 1 41 42 2 1 8 7 6 53 52 51 57 56 55 2...

  • Page 10: Safety Sensor Open And Close

    à The connector plug of the GC 338 has 6 poles. Terminal 6 is not occupied. à For energy-related reasons, the Powerturn can switch the GC 338 automatically to standby mode as long as it is not required. Precondition for this is the Powerturn with firmware from V1.8.
  • Page 11 Powerturn Safety sensor open and close 5. 1 . 1 Monitoring closing and opening Standard operation Set the parameter “Contact type”; à DPS: (normally closed contact) (factory setting). à ST220: Set the “Input signals”, “SI1 – terminal SIS”, “SI1 contact type” to “normally closed contact”...
  • Page 12 Safety sensor open and close Powerturn 5. 1 .2 Monitoring opening Standard operation Set the parameter “Contact type”: à DPS: (normally closed contact) (factory setting). à ST220: Set the “Input signals”, “SI3 – terminal SIO”, “SI3 contact type” to “normally closed contact”...

  • Page 13: Safety Sensor Gc 342

    Powerturn Safety sensor open and close 5. 1 .3 Monitoring closing Standard operation Set the parameter “Contact type”: à DPS: (normally closed contact) (factory setting). à ST220: Set the “Input signals”, “SI1 – terminal SIS”, “SI1 contact type” to “opener”...
  • Page 14 GC 342 Door transmission cable Settings GC 342 à See installation instructions GC 342. à GEZE recommends using the optional remote control to change the sensor parameters. Settings DCU8 Set the parameter “Contact type”: à DPS: (normally closed contact) (factory setting).

  • Page 15: Safety Sensor Gc 334

    Powerturn Safety sensor open and close 5.2.3 Monitoring closing 60 mA 24VSENS Test GC 342 Door transmission cable Settings DCU8 Set the parameter “Contact type”: à DPS: (normally closed contact) (factory setting). à ST220: Set the “Input signals”, “SI1 – terminal SIS”, “SI1 contact type” to “normally closed contact” (factory setting).
  • Page 16 Safety sensor open and close Powerturn 5.3.2 Monitoring opening Set the parameter “Contact type”: GC 334 Module à DPS: (normally closed contact) (factory setting). 13 SIO 60mA à ST220: Set the “Input signals”, “SI3 – terminal SIO1” and “SI3 contact type” to “nor- 24VSENS mally closed contact”...

  • Page 17: Safety Sensor Gc 335

    Powerturn Safety sensor open and close 5.3.4 GC 334 connection over interface GC 334 GC 334 Module GC 334 Module 60mA 24VSENS Interface GC 334 GC 334 Door transmission cable Safety sensor GC 335 à GC 335 master module, mat. no. 128074 GC 335 Extension kit (slave module with accessories), mat. No. 128072 à...
  • Page 18 Safety sensor open and close Powerturn 5.4. 1 Monitoring closing and opening Set the parameter “Contact type”: à DPS: (normally closed contact) and (normally closed contact) (factory setting). à ST220: Set the “Input signals”, “SI1 – terminal SIS1”, “SI1 contact type” to “normally closed contact” and “SI3 –...

  • Page 19: Mechanical Contact

    Powerturn Mechanical contact 5.4.2 Monitoring opening Set the parameter “Contact type”: GC 335 à DPS: (normally closed contact) Slaves (factory setting). 13 SIO à ST220: Set the “Input signals”, “SI3 – terminal 60mA SIO1” and “SI3 contact type” to “nor- mally closed contact”...

  • Page 20: Contact Sensor Inside

    Contact sensor inside Powerturn Contact sensor inside à The input contact sensor inside is active in the operating modes AU and LS. à In the case of 2-leaf systems the contact sensor inside can be connected to the active leaf control or to the passive leaf control.

  • Page 21: Contact Sensor Outside

    Powerturn Contact sensor outside Contact sensor outside à The input contact sensor outside is only active in the AU operating mode. à In the case of 2-leaf systems the contact sensor outside can be connected to the active leaf control or to the passive leaf control.

  • Page 22: Radio Control

    Set the radio reception board WRB-5 (1) onto spacer (2) and connector strip (4). Move the aerial to the right position, see illustration. Transmitting module WTM Transmitting module WTM, mat. no. 131212 For further instructions see the installation and service instructions GEZE Automatic Wireless Program...

  • Page 23: Push & Go

    Powerturn Push & Go Push & Go WARNING Danger of injury due to crushing and shearing! During an activated Push & Go function door handles can form potential danger points. à The Push & Go function allows activation of the drive without contact sensors being used.

  • Page 24: Opening 2-Leaf And 1-Leaf

    Configurable inputs Powerturn 11.2 Opening 2-leaf and 1-leaf à The configurable inputs of the active leaf control can be used to change between the operating modes 2-leaf opening or 1-leaf opening as required (depending on the parameter setting). This can, for example, be advisa- ble if the type of opening is switched by a timer via the available programme switching inputs (NA, LS, AU, DO).

  • Page 25: Emergency Lock

    Powerturn Configurable inputs 11.5 Emergency lock WARNING Danger of injury due to crushing and shearing! The safety sensors and obstruction are not evaluated. The door closes with the set force. If the door closes unexpected, move out of the danger zone.

  • Page 26: Controller Reset

    Configurable inputs Powerturn 11.7.3 Switch function hold-open time (OHZ) In the case of 2-leaf drives, the settings on the active leaf control determine the hold-open time. for: 1st switch contact = open door / 2nd switch contact = close door If the SIO is triggered before the hold-open time or the 2nd switch contact is activated, the hold-open time runs and is not cancelled by the 2nd switch contact.

  • Page 27: Stop

    Powerturn Configurable inputs 11. 1 0 STOP The configurable inputs PE1, PE2 and PE3 can be used for connection of a stop push button or sensor strip. The inputs PE2 and PE3 can also be evaluated in the same way.

  • Page 28: Wc Control

    Configurable outputs Powerturn 11. 1 2 WC control Connection of the internal push button for the WC function, refer also to chapter 15. 11. 1 3 Fire alarm Refer also to Chapter 28.2.1. 11. 1 4 1-leaf opening à The passive leaf must be switched on.
  • Page 29 PA1B 12. 1 .5 Electric strike The electric strike function is not permissible if the drive is used for the fire-protection area (Powerturn F, F/R, F-IS with fire protection kit). à An additional electric strike can be connected to the configurable output PA1.
  • Page 30 Configurable outputs Powerturn Drive-side supplied electric strike Free-wheeling diode 1N4007, mat. no. 115293 PA1A Wire jumper PA1B On-site supplied electric strike ~ 12V AC ~ à Contact load output PA1 at 12 V AC: max. 1 A max. 1A PA1A PA1B Bolt message (RM) See chapter 13 “Electric strike”, “Bolt message”.
  • Page 31 Powerturn Configurable outputs 12. 1 .7 Light control WARNING Risk of fatal injury due to electric shock. Danger of damage to the electrical control! The output PA1 of the control cannot switch the illumination directly. Do not connect mains voltage to the PA1 output of the control.

  • Page 32: Configurable Output Pa2

    Configurable outputs Powerturn 12.2 Configurable output PA2 PA2 is a transistor output, switching voltage/current max. 24 V DC / 0.5 A. 12.2. 1 Gong The output is selected, if KA or SIS (for a “SIS and KA” setting) is activated. à Set the parameters with: à...
  • Page 33 Configurable outputs 12.2.5 Electric strike à The electric strike function is not permissible if the drive is used for the fire protection area (Powerturn F, F/R, F-IS with fire protection kit). à Only inductive DC electric strikes (without integrated electronics) may be connected to PA2. Electric strikes with integrated electronics must be connected to the configurable output PA1, see chapter 12.1.5, “Electric...

  • Page 34: Electric Strike

    à Motor lock with panic function GEZE IQ Lock EL for 1-leaf doors. The GEZE IQ Lock EL is a self-locking anti-panic motor lock with external control. See wiring diagram for motor lock IQ Lock EL. IQ Lock SecuLogic set (Motor lock PZ-bored, complete, incl.

  • Page 35: Dc Electric Strike Supplied On Drive Side

    13. 1 24V DC electric strike supplied on drive side GEZE electric strikes for standard applications, doors with access control GEZE electric strike Mat. no. Current consump-...

  • Page 36: Bolt Message

    Free cable connections Powerturn 13.3 Bolt message If active, then DPS switches to the mode of operation night mode. A mode of operation LED on the drive indicates the mode of operation (e.g. mode of operation automatic in green). à Input RM blocks the activation of the drive when the door is locked. If the Input RM becomes active while the door is open, the door reverses and remains open.

  • Page 37: Wc Control

    Powerturn WC control WC control Only operates with fail-safe electric strike. For connection and parameter setting, see chapter 13 “Electric strike”. oder PE1, PE2 PE1, PE2 oder oder PA1 PA2 PA1 PA2 PA1A PA1A PA1B PA1B Inside push button (switch unit with illuminated display)

  • Page 38: Mode Of Operation

    See chapter 6.1 “Key switch”. Mode of operation The modes of operation are described in the Powerturn user manual. à Operation of the display programme switch DPS see chapter 29.4 “Display programme switch (DPS)”. à Operation of the service terminal ST220 see chapter 29.1 “Service terminal ST220”.
  • Page 39 Powerturn Mode of operation Mechanical programme switch (MPS-D) à MPS-D, AS500, mat. no. 118417 à MPS-D-ST, with key, AS500, mat. no. 118418 à Accessories: Surface-mounted cap, single, AS500, mat. no. 120503 à For 2-leaf systems, the MPS-D is connected to the active leaf.

  • Page 40: Set The Operating Mode Using Push Buttons Or Switches

    Mode of operation Powerturn Blocking or releasing DPS operation à Blocking operation by key operating switch Operation of the DPS can be blocked/released by connecting a key switch to prevent the mode of operation be- ing changed by unauthorised persons.

  • Page 41: Change In Operating Mode

    Powerturn Mode of operation 16.3 Change in operating mode 16.3. 1 Changing the operating mode using the operating modes push button/operating modes display Changing the operating mode (with single-leaf doors or active leaves) Press the operating modes key (1) briefly.

  • Page 42: 17 2-Leaf Drives

    Hold open ○ LED off ● LED on 2-leaf drives 17. 1 Powerturn IS/TS: Active leaf automated, passive leaf with door closer à Reed switch, mat. no. 92777 PE1 GF oder PE2 GF oder PE3 GF à The closed position of the passive leaf is monitored with a reed switch.

  • Page 43: Two Automated Door Leaves

    Powerturn 2-leaf drives 17.2 Two automated door leaves à For parameter settings, see chapter 22 “Commis- RS485 GF RS485 SF sioning and service”. RS485_B RS485_B Establish RS485 connection between both drives RS485_A RS485_A via system cable mat. no. 120048 or mat. no. 120061, see chapter 17.3 “Connection via system cable...

  • Page 44: Smoke Switch Control Unit

    This is useful for additional devices which are installed under the intermediate cover. Smoke switch control unit The required fire protection kit (mat. no. 154876) for Powerturn includes: à F-board DCU801 with fastening screws and spacer à Reset push button Installing the F-board DCU801 A jumper must be inserted for controls without an F-board.
  • Page 45 Powerturn Smoke switch control unit Press F-board (2) onto the control circuit board DCU800 (3). Screw F-board (2) tightly. à For a 2-leaf drive the smoke control unit has to be connected to the same control as the drive's reset push button.
  • Page 46 Smoke switch control unit Powerturn Before putting into service and during servicing, with floating DCU8-F SF DCU8-F GF DCU801 DCU801 (zero current) drive, the setting of the latching action switch and the function of the braking circuit must be checked by manually opening the door.

  • Page 47: Integrated Smoke Switch Powerturn F/R

    18. 1 Integrated smoke switch Powerturn F/R For reasons of appearance the GEZE lintel smoke switch can be integrated in the extension kit or the intermedi- ate cover kit. The extension kit or the intermediate cover kit is supplied with a fixture for this purpose. The smoke switch is inserted into it and the electrical connection is established.

  • Page 48: Powerturn F- Is/Ts, F/R-Is/Ts Hold-Open System - Automatic Active Leaf, Passive Leaf With Door Closer And Holding Magnet

    18.2 Powerturn F- IS/TS, F/R-IS/TS hold-open system – automatic active leaf, passive leaf with door closer and holding magnet The Powerturn F-IS/TS and Powerturn F/R-IS/TS hold-open systems are systems where the active leaf is automat- ed with a Powerturn and the passive leaf has a mechanical door closer.
  • Page 49 DCU802 PA1A PA1B 63mA DCU801 +24V RSZGND RSZ 24V RSZGND 10mA Powerturn F/R- active leaf Passive leaf with door closer Reed switch for the pas- sive leaf closed position Holding magnet Integrated smoke switch GC 151 +24V External hold-open unit...

  • Page 50: Mains Connection

    Mains connection Powerturn Mains connection Transom installation 230V 50Hz GN/YE Mains fuse To second drive Main switch (optional) Mounting plate Control AC IN 230 V T-distributor, mat. no. 166272 Transformer 230 V 50 Hz additional device, max. 700 W Main switch, internal...

  • Page 51: Mounting Plate With Integrated Feeder

    Powerturn Mains connection 19. 1 Mounting plate with integrated feeder 19. 1 . 1 Composition à Make sure the mounting plate is in the correct position, see directional arrow (1). à Mains connection always on the hinge side. à The connection to the drive is on the facing side.
  • Page 52 Powerturn 19. 1 .3 Connecting to the mains If the mains supply line is connected to the installed drive, the connection board DCU802 must be removed. See Powerturn installation instructions. Strip the mains (1). 9 mm à Stripping length = 40 mm à...

  • Page 53: Motor

    Powerturn Motor à In the connected state, the rubber grommet (4) must enclose the connector (3) and cable (1) completely. à No individual wires may be visible. Motor WARNING Danger of injury through link arm or lever arm snapping back! Danger of injury with hot motor! Disconnect motor from the control only if spring is relaxed.

  • Page 54: Control

    Control Powerturn Control Slot for F-board DCU801 LED solenoid Service buttons and service LEDs PROG LED 24V ext Slot for radio board WRB-5 Brake FREE Ventilator 24 V Encoder RS485 Motor Safety fuse F1, AC IN (10 A T, 5 × 10 mm)

  • Page 55: Commissioning And Service

    22.2 Teaching run à For the teaching run to be carried out, the drive must be completely installed and supplied with voltage. à The spring force required (EN4 – 7) must be set before the teaching run, see Powerturn installation instruc- tions.

  • Page 56: Teaching A 1-Leaf System

    Commissioning and service Powerturn 22.3 Teaching a 1-leaf system step Actions ST220 display DPS display Service LED  display (5 Select parameter “Start learning” and press the ENTER Start teaching key. Select 1-leaf system. Start the respective learning in DPS (NT): à...

  • Page 57: Teaching A 2-Leaf System

    Powerturn Commissioning and service 22.4 Teaching a 2-leaf system Teaching a 2-leaf system with service keys is not possible. step Actions ST220 display Service LED display  display (5 Select parameter “Start learning” and press the ENTER Start teaching key.

  • Page 58: Forces And Speeds

    De-energised mode Powerturn 22.5 Forces and speeds 22.5. 1 Forces The forces set using “Opening force” (FO), “Opening retention force” (0F), “Closing retention force” (CF), “Force closed position” (FS) or “Closing force” (FC) always refer to N at the main closing edge.

  • Page 59: Resilience To External Influences Or Load Due To Wind Pressure

    Powerturn Resilience to external influences or load due to wind pressure Resilience to external influences or load due to wind pressure In the event of exposed exterior doors with high load due to wind pressure or doors exposed to overpressure, the drive can be set using the “Opening force, FO”, “Closing force, FC”...

  • Page 60: Low-Energy Mode

    à In the case of 2-leaf doors both drives must be set to low-energy operation. The Powerturn drive can be operated as a low-energy drive if the following conditions are met: à in a disconnected state: à...

  • Page 61: Servo Mode

    Powerturn Servo mode Servo mode The GEZE Powerturn drive can be operated as a servo drive. It supports the user torque-controlled during manual opening. The servo drive is operated and set within the automatic mode of operation. The force support is divided into 2 functional areas: à...
  • Page 62 Servo mode Powerturn PE1 PE2 oder 52 PE2 Customer building control centre Floating “Fire alarm” output WARNING Risk of injury due to high dynamic forces of the servo function with fire alarm! Make sure that no individuals are located near the door when opening in the event of a fire alarm.

  • Page 63: Service Menu

    “F1” the drive changes to safety switch-off and sets the fault “Wrong HW/SW combination”. Display after setting up connection to the door control Drive type Software version 1.8, hardware version F0 Powerturn 1.8 F0 DCU800 Basic board DCU200 Automatic Mode of operation...

  • Page 64: Connecting Service Terminal St220

    Service menu Powerturn 29.2 Connecting service terminal ST220 Service terminal ST220 is connected to connection board DU802 (3) using the bushing for the 3.5 mm TRS con- nector (1) or alternatively at the connector plug for DPS (2). 29.3 Service menu ST220 See chapter 29.6 “DPS service menu and service buttons S1/S2 with LEDs”...
  • Page 65 Powerturn Service menu 29.3.3 Mode of operation Designation Setting values Explanation Mode of opera- Operating mode setting tion * Night mode Exit only Automatic Hold open 1-leaf opening Opening type Only open active leaf. 2-leaf opening Open active and passive leaves when activated.
  • Page 66 2. Sub-menu Explanation Speeds Opening time Value: Opening time with automatic opening. Setting pursuant to the table in the Powerturn installation instructions. Closing time Value: Closing time as per automatic/ manual opening. Setting pursu- ant to the table in the Power- turn installation instructions.
  • Page 67 Powerturn Service menu Designation 1. Sub-menu 2. Sub-menu Explanation Braking force Value: Value Braking force during closing via spring action following power failure or fire alarm. 150 N Forces Opening force Value: Open static force at the main 10 N closing edge.
  • Page 68 Service menu Powerturn Designation 1. Sub-menu 2. Sub-menu Explanation Close delay GF -> EN16005/DIN18650 0 s: both leaves close simultane- ously. 01 … 15 s: The active leaf closes some time after the passive leaf. 16 s 16 s: Active leaf does not close until after the passive leaf has closed completely.
  • Page 69 Powerturn Service menu Designation 1. Sub-menu 2. Sub-menu Explanation Setting opening width Value: 0 degrees The value is only for fine adjust- min. -9 degrees ment. The value is taught during max. 9 degrees the teaching run and then cor- responds to point 0.
  • Page 70 Service menu Powerturn Designation 1. Sub-menu 2. Sub-menu 3. Sub-menu Explanation SIS stop If the safety sensor “close” trig- gers, the drive stops. SIS manual not active Closing safety sensor active/ active inactive when closing after manual opening in door close mode.
  • Page 71 Powerturn Service menu Designation 1. Sub-menu 2. Sub-menu 3. Sub-menu Explanation current state Z->not active K-> NO contact A->*0.1s KI contact type not used The input KI is active in AU and NO contact LS mode. For 2-leaf assemblies NC contact...
  • Page 72 Service menu Powerturn Designation 1. Sub-menu 2. Sub-menu 3. Sub-menu Explanation OFF contact not used NO contact type NC contact current status Z->not active K->not used F->not used not used PE1 function Switchover summer For the connection of a push button for the summer function.
  • Page 73 Powerturn Service menu Designation 1. Sub-menu 2. Sub-menu 3. Sub-menu Explanation Switch function OHZ On activation, the output of the push button is closed. For 2-leaf assemblies the push button can be connected to the active leaf control or to the passive leaf control.
  • Page 74 Service menu Powerturn Designation 1. Sub-menu 2. Sub-menu 3. Sub-menu Explanation Closing position GF NO Closed position contact of the door leaf à For 1-leaf door à For 1-leaf door drive with manual passive leaf (door closer): Closed position contact of the active leaf à...
  • Page 75 Powerturn Service menu Designation 1. Sub-menu 2. Sub-menu 3. Sub-menu Explanation current state Z->not active K->not used F->not used not used PE3 function MPS For connection of an MPS. Selector switch For the connection of a push Summer button for the summer function.
  • Page 76 Service menu Powerturn Designation 1. Sub-menu 2. Sub-menu 3. Sub-menu Explanation 1-leaf opening In the 2-leaf system the door is only opened 1-leaf if the signal is active on the active leaf. Display only for 2-leaf drives. Mode of opera-...
  • Page 77 Powerturn Service menu Designation 1. Sub-menu 2. Sub-menu 3. Sub-menu Explanation Holding magnet For setting the holding magnet (passive leaf) WC timeout To connect a lamp or a signal to signal when the 30-min. timer has expired for the WC function.
  • Page 78 Service menu Powerturn 29.3.7 Diagnosis Designation 1. Sub-menu 2. Sub-menu Explanation Current values Inputs 0.0 V 0.0 V Latching act Outputs closed TEST Internal values current position current motor power Mot DCU800 0.0 A Voltages Mains 24 V internal xy.z V 24 V external xy.z V...
  • Page 79 Powerturn Service menu Designation 1. Sub-menu 2. Sub-menu Explanation Outputs TEST Fault memory Current faults Fault 1 Cause 1 Cause 2 Fault 2 Cause 1 Cause 2 Fault 3 Cause 1 Cause 2 Fault 4 Cause 1 Cause 2 Old faults...
  • Page 80 à If the password has been forgotten, a special flash file with which the password on the control can be reset to 00 has to be requested from GEZE. à The password cannot be deleted by installing a new software version 29.3.

  • Page 81: Display Programme Switch (Dps)

    Powerturn Service menu 29.4 Display programme switch (DPS) The DPS can be used for commissioning and servicing, mat. no. 151524: à for changing the drive parameters à for teaching the drive à for diagnosis Mode of operation Service mode Night mode ×...
  • Page 82 Service menu Powerturn System messages à If one or more faults are pending, these are displayed consecutively alternatively with the current mode of operation in encoded form with service LEDs 1 to 4. à The red LED5 flashes quickly (10 Hz) on the fault display.

  • Page 83: Dps Service Menu And Service Buttons S1/S2 With Leds

    Setting values Explanation ○ ○ ○ ● Opening time 03...04... 06... 25 in s; Opening time with automatic opening. Set- ting pursuant to the table in the Powerturn installation instructions. ○ ○ ● ○ 05 … 06 … 25 Closing time in s; ○ ●...
  • Page 84 Service menu Powerturn DPS Service-LEDs Parameter Setting values Explanation ● ● ○ ○ Electric strike type No electric strike Fail-secure Drive does not have closing force (pressure in the closed position) before opening. Fail-safe Motor lock Working closing pressure Drive has closing force (pressure in the closed position) before opening.
  • Page 85 Powerturn Service menu 2. Menu DPS Service-LEDs Parameter Setting values Explanation – – – – – Push & Go hold-open in s; times 01 … 10 Hold-open time during passage with Push 12 … 20 & Go. 25 … 50 – – – – – Hold-open times, in s;...
  • Page 86 Service menu Powerturn DPS Service-LEDs Parameter Setting values Explanation – – – – – Servo fire alarm 00 … 70 in Nm; Adjustable torque of force support for fire alarm, if 24 V is applied to PE1 or PE2. Acts in addition to “additional servo torque”.
  • Page 87 Powerturn Service menu 3. Menu DPS Service-LEDs Parameter Setting values Explanation – – – – – Hold-open time KB 00 … 01 … 10 in s; 12 … 20 Hold-open time after activation with KB. 25 … 50 – – – – – Dyn extension When activated, the passage frequency is taken into account in the hold-open time.
  • Page 88 Service menu Powerturn DPS Service-LEDs Parameter Setting values Explanation – – – – – KB contact type Not used The input KB is active in the operating NO contact modes AU, LS and NA. For 2-leaf assemblies NC contact the mechanical contact can be connected to the active leaf control or to the passive leaf control.
  • Page 89 Powerturn Service menu DPS Service-LEDs Parameter Setting values Explanation Switch function NO On activation, the output of the push but- ton is closed. For 2-leaf assemblies the push button can be connected to the active leaf control or to the passive leaf control. If the...
  • Page 90 Service menu Powerturn DPS Service-LEDs Parameter Setting values Explanation Sabotage NC Permanently switched. If the contact is interrupted KB is not evaluated in the night mode of operation. All other functions remain the same. Closed position GF NO Closed position contact of the door leaf à...
  • Page 91 Powerturn Service menu DPS Service-LEDs Parameter Setting values Explanation Fault MPS The function is used to switch the fault LED at the MPS. The contact closes if the control determines a fault. When maintenance is due, the output is switched cyclically, the fault LED at the MPS flashes.
  • Page 92 Service menu Powerturn DPS Service-LEDs Parameter Setting values Explanation – – – – – Closed position force 00 … 01 … 15 x10 N, force acts after expiry of the latching action in the closed position. Manual open- ing is more difficult during the set time.

  • Page 93: Fault Messages

    Powerturn Fault messages Fault messages 30. 1 Fault messages ST220 and DPS 30. 1 . 1 Fault display On the DPS à For troubleshooting and fault description see also list “Faults and actions - control DCU2” list. à Currently queued fault messages are displayed on the display programme switch in cycles (10 s). In addition, they are also entered in the fault memories.
  • Page 94 Fault messages Powerturn Fault no. Message Message on the ST220 Fault description on the DPS Rotate angle A cam skip has been detected. Defective magnetic valve The solenoid valve of the energy store is defective. Mechanical fault SF A mechanical fault has occurred at the passive leaf; collective fault.
  • Page 95 Powerturn Fault messages Fault no. Message Message on the ST220 Fault description on the DPS Ctrl. DCU800 Internal control fault, collective fault for active leaf. EEPROM value – EEPROM comparison – Fault current measurement Error in motor current measurement. EEPROM time-out –...

  • Page 96: Fault Messages On The Service Button Leds

    Fault messages Powerturn 30.2 Fault messages on the service button LEDs à Fault messages of fault groups are displayed on the service button LEDs. The exact fault can be determined using the fault number in chapter 30.1.2. à For the service button LEDs, LED 5 flashes at 10 Hz.
  • Page 97 Powerturn...
  • Page 98 Tel. +49 (0) 7152 203 594 www.geze.at www.geze.hu www.geze.dk Email: leonberg.de@geze.com Baltic States Iberia Singapore GEZE GmbH Baltic States office GEZE Iberia S.R.L. GEZE (Asia Pacific) Pte, Ltd. GEZE GmbH Email: office-latvia@geze.com Email: info@geze.es Email: gezesea@geze.com.sg Branch Office South-East www.geze.com www.geze.es...
