Converting the TS units

8 Converting the TS units
8. 1 TS 5000 L - conversion from DIN right to DIN left
This chapter describes the conversion work necessary if TS 5000 L is to have a DIN left installation.
8. 1 . 1 TS 5000 L is delivered for DIN right installation from the factory
8. 1 .2 Converting the TS 5000 L
1
4
4 Nm
(2 ×)
12
2
1
6
3
5
7
1 Nm
(2 ×)
