Powerturn F/R-IS/TS
Converting the TS units
Attach the wire rope and spring on the wire rope tensioner
1
2
3
~0.2 Nm
4
SW 1.5
1
2
Set screw (1), tension spring (2)
~0.2 Nm
5
3
Position of the setting lever (3) = brake opened, active leaf closing.
19
