- Page 1 GEZE EN Installation instructions Powerdrive PL-HT Hermetic sliding door system 142030-02...
-
Page 2: Table Of Contents
Powerdrive PL-HT Table of contents General information ...............................3 Key to symbols ........................................3 Product liability .........................................3 Safety ...................................4 Intended use........................................4 Safety instructions ......................................4 Information for safety-conscious working ..............................5 Inspection of the installed system ................................5 Environmentally conscious working .................................5 Overview..................................6 Diagrams ..........................................6 Installation ..................................7... -
Page 3: General Information
Powerdrive PL-HT General information General information 1. 1 Key to symbols In these instructions warnings are used to warn against material damage. Always read and observe these warnings! Warning Warning word Meaning symbol Danger for individuals. WARNING Non-compliance can result in death or serious injuries. -
Page 4: Safety
Safety 2. 1 Intended use The Powerdrive PL-HT is an automatic sliding door system with sealing door leaves in the closed position. The Powerdrive PL-HT is designed solely for use à In dry rooms, à In automatic door systems for horizontally moving door leaves, à... -
Page 5: Information For Safety-Conscious Working
Powerdrive PL-HT Safety Information for safety-conscious working à Secure workplace against unauthorised entry. à Watch swivelling range of long system parts. à Never carry out work with a high safety risk (e.g. installing the drive, cover or door leaf) while alone. -
Page 6: Overview
Overview Powerdrive PL-HT Overview 3. 1 Diagrams Number Designation 70722-9-0950 PL-HT installation instructions 160924 Wiring diagram 164883 Wiring diagram supplement 168222 User manual 134358 Safety analysis 108104 Errors and corrective measures The diagrams are subject to change without notice. Use only the most recent version. -
Page 7: Installation
Powerdrive PL-HT Installation Installation Check the preparations by the customer on site: à Type and load bearing capacity of the façade construction or base construction à Evenness of the installation surface à Levelness of the floor in the passage area: ± 1 mm height difference / m 3x M6x12 min. - Page 8 Installation Powerdrive PL-HT M6x10 *) Not GEZE scope of delivery...
- Page 9 Powerdrive PL-HT Installation 3x M6x16 *) Not GEZE scope of delivery...
- Page 10 Installation Powerdrive PL-HT M3x16 90° Ø 3,4 Ø 6,5...
- Page 11 Powerdrive PL-HT Installation St 3,9x32 St 3.9x32...
- Page 12 Installation Powerdrive PL-HT...
- Page 13 Powerdrive PL-HT Installation...
- Page 14 Installation Powerdrive PL-HT...
- Page 15 Powerdrive PL-HT Installation...
- Page 16 Installation Powerdrive PL-HT Install and connect all the drive components (see installation instructions Powerdrive PL/PI-FR). Connect all the existing operating (e.g. programme switches, etc.), triggering (e.g. movement detectors, etc.) and safety elements (e.g. light curtains, etc.) (see wiring diagram). Install the accessories.
-
Page 17: Commissioning
Powerdrive PL-HT Commissioning Commissioning A display programme switch DPS has to be connected to the controller for the commissioning process. WARNING! DANGER OF FATAL INJURY DUE TO ELECTRIC SHOCK! Get a qualified electrician to connect and disconnect the electrical system (230 V). - Page 18 Commissioning Powerdrive PL-HT M6x10...
- Page 19 Powerdrive PL-HT Commissioning...
- Page 20 Commissioning Powerdrive PL-HT...
-
Page 21: Maintenance
Maintenance Maintenance The general maintenance work for sliding door systems is described in the user manual. This chapter describes supplementary maintenance work for the Powerdrive PL-HT. 6. 1 Maintenance intervals The owner must ensure that the system functions properly. In order to ensure faultless operation, the door sys- tem has to be maintained by a service technician when the maintenance indicator lights up. - Page 22 Commissioning Powerdrive PL-HT...
- Page 23 Powerdrive PL-HT Commissioning...
- Page 24 E-Mail: danmark.se@geze.com Tel. +49 (0) 7152 203 594 www.geze.at www.geze.hu www.geze.dk E-Mail: leonberg.de@geze.com Baltic States Iberia Singapore GEZE GmbH Baltic States office GEZE Iberia S.R.L. GEZE (Asia Pacific) Pte, Ltd. GEZE GmbH E-Mail: office-latvia@geze.com E-Mail: info@geze.es E-Mail: gezesea@geze.com.sg Niederlassung Süd-Ost www.geze.com www.geze.es...
