  • Page 1 Powerturn IS/TS EN Installation instructions Powerturn F-IS/TS Powerturn F/R-IS/TS 164692-01...

  • Page 2: Table Of Contents

    Powerturn F/R-IS/TS Contents Symbols and illustrations ............................3 Product liability ................................3 Security ..................................3 Intended use........................................3 Standards ..........................................3 Reference documents .....................................4 Safety notices ........................................4 Tools and aids ................................4 Types of installation ..............................4 Type of installation transom installation hinge side ...........................4 Type of installation transom installation opposite hinge side ......................4 Types of installation, hinge action ................................5 Fitting dimensions for the installation types ............................6 Product description ..............................8...

  • Page 3: Symbols And Illustrations

    Any other use than the intended use, such as permanent manual operation of the Powerturn F, as well as any modification to the product, is not permitted. Observe the “GEZE Product information for door closers”. The product should be installed or incorporated in such a way that effortless access to the product is guaranteed during any repairs and/or maintenance, and that any removal costs do not stand out of proportion to the value of the product.

  • Page 4: Reference Documents

    Tools and aids Powerturn F/R-IS/TS Reference documents à Powerturn installation instructions à TS 4000 installation instructions à Powerturn wiring diagram à Installation instructions carry bar à Installation instructions for Powerturn à Installation instructions and wiring diagram hold- mechanism for integrated closing sequence open magnet control à...

  • Page 5: Types Of Installation, Hinge Action

    à Loads due to wind pressure, negative pressure or excess pressure must be taken into account. We recommend the installation type involving link arms (wind) for the exterior doors. The Powerturn IS/TS, Powerturn F-IS/TS, and Powerturn F/R-IS/TS permit, with respect to DIN left and DIN right, the following buffer stop types: 5.3.

  • Page 6: Fitting Dimensions For The Installation Types

    Types of installation Powerturn F/R-IS/TS Fitting dimensions for the installation types 5.4. 1 Type of installation transom installation hinge side Dimensional reference - Centre of hinge/Upper edge of door Covered line-feed possible in the hatched area, e.g. Ø 20 mm for the mains connection or low-voltage connection Orientation arrow for precise positioning of the mounting plate Fastening means...
  • Page 7 Powerturn F/R-IS/TS Types of installation 5.4.2 Type of installation transom installation opposite hinge side Fastening - DIN right Fastening DIN left Dimensional reference centre of hinge/bottom edge of frame Covered line-feed possible in the hatched area, e.g. Ø 20 mm for the mains connection or low-voltage connec- tion Orientation arrow for precise positioning of the mounting plate Fastening means...

  • Page 8: Product Description

    Product description Powerturn F/R-IS/TS Product description 6. 1 Illustrations of the TS 5000 L passive leaf unit 6. 1 . 1 TS 5000 L passive leaf unit transom installation hinge side DIN right Single side panel (for Double side panel (for split cover) continuous cover) Rocker for integrated closing sequence control Deflection pulley 6.

  • Page 9: Illustrations Of The Ts 4000 Passive Leaf Unit

    Powerturn F/R-IS/TS Product description Illustrations of the TS 4000 passive leaf unit 6.2. 1 TS 4000 passive leaf unit transom installation opposite hinge side DIN right Single side panel (for Double side panel (for split continuous cover) cover) Rocker for integrated closing sequence control 6.2.2 TS 4000 passive leaf unit transom installation opposite hinge side DIN left Single side panel (for Double side panel (for split...

  • Page 10: Installing The Integrated Powerturn F Closing Sequence Mechanism

    Installing the integrated Powerturn F closing sequence mechanism Powerturn F/R-IS/TS Installing the integrated Powerturn F closing sequence mechanism SW 2.5 2.5 Nm Transom installation opposite hinge side Transom installation hinge side Installation position brake unit: Opposite Hinge Side (OHS) Installation position brake unit: Hinge Side (HS)
  • Page 11 Powerturn F/R-IS/TS Installing the integrated Powerturn F closing sequence mechanism 1 Nm SW 5.5 2.5 Nm SW 2.5 During installation of the setting lever, pay attention to the alignment of the mechanism for integrated closing sequence control (see below). Types of installation: Types of installation: à...

  • Page 12: Converting The Ts Units

    Converting the TS units Powerturn F/R-IS/TS Converting the TS units 8. 1 TS 5000 L - conversion from DIN right to DIN left This chapter describes the conversion work necessary if TS 5000 L is to have a DIN left installation. 8. 1 . 1 TS 5000 L is delivered for DIN right installation from the factory 8.
  • Page 13 Powerturn F/R-IS/TS Converting the TS units 5 Nm (4×) 6 Nm 4 Nm (2 ×) 4 Nm (2 ×)

  • Page 14: Ts 4000 - Conversion From Din Right To Din Left

    Converting the TS units Powerturn F/R-IS/TS TS 4000 - conversion from DIN right to DIN left This chapter describes the conversion work necessary if TS 4000 is to have a DIN left installation. 8.2. 1 TS 4000 transom installation opposite hinge side is delivered for DIN right installation from the factory 8.2.2 Converting the TS 4000...

  • Page 15: Connecting The Mechanism For Integrated Closing Sequence Control Of Active And Passive Leaf

    Powerturn F/R-IS/TS Converting the TS units 5 Nm 6 Nm (4 ×) 4 Nm (2 ×) 4 Nm (2 ×) Connecting the mechanism for integrated closing sequence control of active and passive leaf Install the drive and lever. For drive installation, see installation instructions Powerturn, “prepare for installa- tion”...
  • Page 16 Converting the TS units Powerturn F/R-IS/TS 8.3. 1 Mounting the door closer unit For the installation dimensions, see chapter 5.4. TS 5000 L 8 Nm (2 ×) 8 Nm (2 ×) TS 4000 8 Nm 8 Nm (2 ×) (2 ×) Connection of the active and passive leaf drive: Passive leaf (1) Active leaf (2)
  • Page 17 Powerturn F/R-IS/TS Converting the TS units With continuous cover, remove the side panels. Drill the passage in the side panel for the split cover and deburr (depending on the route of the wire cable): Ø 2 mm Route of wire cable near the passive leaf unit: TS 5000 L DIN right TS 4000 DIN right TS 5000 L DIN left...
  • Page 18 Converting the TS units Powerturn F/R-IS/TS Route of wire cable near the control: Position of setting lever with the brake closed Position of setting lever with the brake opened Motor Motor...
  • Page 19 Powerturn F/R-IS/TS Converting the TS units Attach the wire rope and spring on the wire rope tensioner ~0.2 Nm SW 1.5 Set screw (1), tension spring (2) ~0.2 Nm Position of the setting lever (3) = brake opened, active leaf closing.

  • Page 20: Install Carry Bar

    Converting the TS units Powerturn F/R-IS/TS Set the retaining action of the integrated closing brake SW 2.5 The correct setting of the entire mechanism for integrated closing sequence control has been achieved when, with the brake closed and passive leaf closed, the setting lever takes up the position as designated for the open brake. The wire rope must be tensioned both with opened and closed integrated closing brake between the passive and active leaf unit.

  • Page 21: Installing The Electrical Contact For Passive Leaf Position Monitoring

    Powerturn F/R-IS/TS Function check Installing the electrical contact for passive leaf position monitoring To monitor the position of the passive leaf, the enclosed electrical contact must be installed on the passive leaf to ensure the proper function of the closing sequence control of the door leaves in the Powerturn’s automatic mode If necessary, information must be obtained from the door manufacturer if the passive leaf is mechanically treated for installation of the contact and wiring.

  • Page 22: Service And Maintenance

    Service and maintenance Powerturn F/R-IS/TS Service and maintenance 11. 1 General information The maintenance work on the closing sequence control must be carried out by an expert during the maintenance cycle of the Powerturn drive. à For maintenance instructions for the Powerturn swing door drive, see Powerturn installation instructions “Service and maintenance”...

  • Page 23: Troubleshooting

    Powerturn F/R-IS/TS Troubleshooting Troubleshooting For troubleshooting and fault elimination see the fault table in the Powerturn wiring diagram, "Fault messages" section.
