- Page 1 Powerturn EN Installation manual Mechanism for integrated closing sequence control 158635-03...
-
Page 2: Table Of Contents
Powerturn mechanism for integrated closing sequence control Contents Symbols and illustrations .............................3 Product liability ................................3 Safety ...................................3 Proper use ..........................................3 Standards ..........................................3 Reference documents .....................................3 Safety notices ........................................3 Tools and aids ................................4 Types of installation ..............................4 Type of installation transom installation hinge side ..........................4 Type of installation transom installation opposite hinge side ......................4... -
Page 3: Symbols And Illustrations
Safety Proper use The Powerturn IS closing sequence control has been designed for mechanical control during the closing of double-leaf single-action swing leaf doors. The construction components required are a supplement to the Powerturn drive and must be installed according to these instructions. -
Page 4: Tools And Aids
Type of installation transom installation opposite hinge side With this type of installation, both link arms as well as roller guide rail and lever can be used. Details about permissible reveal depth, door overlap and installation holes can be found in the Powerturn installation manuals. passive leaf active leaf Door leaf installation is not possible with mechanical, integrated closing sequence control. -
Page 5: Product Description
Powerturn mechanism for integrated closing sequence control Product description Product description Areas of application See Powerturn installation manuals for mechanical and electrical data. Drive unit with pre-mounted mechanism for integrated closing sequence control 6.2.1 Active leaf drive transom installation hinge side DIN left... - Page 6 Product description Powerturn mechanism for integrated closing sequence control 6.2.3 Active leaf drive transom installation hinge side DIN right 1 2 3 4 5 Brake unit Setting lever Wire cable tensioner Tension spring for tautening the wire cable Spring attachment 6.2.4 Passive leaf drive transom installation hinge side DIN left...
- Page 7 Powerturn mechanism for integrated closing sequence control Product description 6.2.5 Active leaf drive transom installation opposite hinge side DIN right Brake unit Setting lever Wire cable tensioner Tension spring for tautening the wire cable Spring attachment 6.2.6 Passive leaf drive transom installation opposite hinge side DIN left...
- Page 8 Product description Powerturn mechanism for integrated closing sequence control 6.2.7 Active leaf drive transom installation opposite hinge side DIN left 1 2 3 4 5 Brake unit Setting lever Wire cable tensioner Tension spring for tautening the wire cable Spring attachment 6.2.8 Passive leaf drive transom installation opposite hinge side DIN right...
-
Page 9: Installing The Integrated Closing Sequence Mechanism
Powerturn mechanism for integrated closing sequence control Installing the integrated closing sequence mechanism Installing the integrated closing sequence mechanism Installing the mechanism for integrated closing sequence control for the active leaf drive SW 2,5... - Page 10 Installing the integrated closing sequence mechanism Powerturn mechanism for integrated closing sequence control Transom installation opposite hinge side. Transom installation hinge side Installation position brake unit: Opposite Hinge Side (OHS) Installation position brake unit: Hinge Side (HS) SW 5,5 SW 2,5 During installation of the setting lever, heed the adjustment of the mechanism for integrated closing sequence control as set out in chapter 6.2.
-
Page 11: Install The Mechanism For Integrated Closing Sequence Control For The Passive Leaf Drive
Powerturn mechanism for integrated closing sequence control Installing the integrated closing sequence mechanism Install the mechanism for integrated closing sequence control for the passive leaf drive Transom installation hinge side Damage to the rocker for integrated closing sequence control by the integrated closing counter piece. - Page 12 Installing the integrated closing sequence mechanism Powerturn mechanism for integrated closing sequence control Transom installation opposite hinge side. Damage to the rocker for integrated closing sequence control by the integrated closing counter piece. When the IS-mechanism has been pre-mounted, only put the passive leaf drives into electrical operation when the drives with roller lever or link arm have been installed on the door.
-
Page 13: Connecting The Mechanism For Integrated Closing Sequence Control Of Active And Passive Leaf
Installing the integrated closing sequence mechanism Connecting the mechanism for integrated closing sequence control of active and passive leaf Install the drives and levers. See the Powerturn installation manuals for details of drive installation. Connection of the active and passive leaf drive: Passive leaf (1) Active leaf (2) For wire cable connection see chapter 6.2 “Drive unit with pre-mounted mechanism for integrated closing... - Page 14 Installing the integrated closing sequence mechanism Powerturn mechanism for integrated closing sequence control With continuous cover, remove the additional side panels. Drill passageways in additional side panels for divided cover: Ø 2 mm Route of wire cable near the control:...
- Page 15 Powerturn mechanism for integrated closing sequence control Installing the integrated closing sequence mechanism Attach the wire cable and spring on the wire cable tensioner SW 1.5 Setscrew (1), tension spring (2) Position of the setting lever (3) = brake opened, active leaf closing.
- Page 16 Installing the integrated closing sequence mechanism Powerturn mechanism for integrated closing sequence control Set the retaining action of the integrated closing brake SW 2,5 The correct setting of the entire mechanism for integrated closing sequence control has been achieved when, with the brake closed and passive leaf closed, the setting lever takes up the position as designated for the opened brake.
-
Page 17: Function Check
Powerturn mechanism for integrated closing sequence control Function check Function check Open the active and passive leaves up to the waiting position. Release the passive and active leaves. The passive leaf must start the closing movement immediately. The active leaf must remain in position until the brake is opened by the mechanism for integrated closing sequence control on the passive leaf. -
Page 18: Commissioning
Commissioning Powerturn mechanism for integrated closing sequence control Commissioning See Powerturn installation manuals and wiring diagram for electrical connection, spring force setting and teaching process. Service and maintenance à The maintenance work on the closing sequence control must be carried out by an expert during the maintenance cycle of the Powerturn drive. - Page 19 Powerturn mechanism for integrated closing sequence control Commissioning...
- Page 20 E-Mail: leonberg.de@geze.com Baltic States Iberia Scandinavia – Norway Lithuania / Latvia / Estonia GEZE Iberia S.R.L. GEZE Scandinavia AB avd. Norge GEZE GmbH E-Mail: norge.se@geze.com E-Mail: baltic-states@geze.com E-Mail: info.es@geze.com Niederlassung Süd-Ost www.geze.no www.geze.es Tel. +49 (0) 7152 203 6440 E-Mail: muenchen.de@geze.com...
