4.4.4.7 Antifreeze Protection
Protection Antifreeze can be configured ON in the
Freezing presents risks to pools and pool equipment. Expansion of the water as it moves from the liquid to the solid state can crack
pipes and burst fittings, as well as the filter and the pump body.
PoolCop has two means of detecting a freezing risk. It is recommended that BOTH freezing protections be utilised and that freezing
protection be selected ON in the
PoolCop freezing protections can only assist in the protection of equipment. PoolCop cannot guarantee that
When freezing risk is detected and filtration started, the pump CANNOT be stopped until the temperature
detected is higher than the protection setting or the Protection Antifreeze is switched OFF in the Pool Data
4.4.4.7.1 Internal Freezing Protection (for equipment)
Internal temperature sensing detects low temperature and starts the filtration to move warmer water from the pool through the
plumbing to reduce the risk of damage due to freezing, if the protection is
to a certain degree.
If the PoolCop temperature sensor, installed in the multiport valve housing, detects a temperature < 2°C, the Alert "WARN:
FREEZING RISK" will display, and freezing protection will be activated if freezing protection is ON in the
filtration will run at all times that the temperature is less than 2°C, and will continue for a period of 30 minutes after the temperature
rises above 2°C.
4.4.4.7.2 External Freezing Protection (for the pool)
There can be great differences in temperature between the pump and filter installation and the pool itself. The optional Air
Temperature Sensor is highly recommended so that external air temperature can be used to alert to the risk of freezing and start
filtration.
If the optional Air Temperature Sensor is fitted, measured temperature is used to trigger antifreeze protection when temperature is
below -5°C. The Alert "WARN: FREEZE RISK" will display, and freezing protection will be activated if freezing protection is
the POOL DATA menu. The filtration will run at all times that the temperature is less -5⁰C, and will continue for a period of 30
minutes after the temperature rises above -5⁰C.
Alternatively an external thermostat can be installed and connected to an input channel so that external air or water temperature
can be used to alert to the risk of freezing and start filtration. When an external thermostat sensor is connected and configured on
one of the inputs and detects a temperature lower than the thermostat settings, the Alert "WARN: FREEZE RISK"" will display, and
freezing protection will be activated if freezing protection is ON in the
temperature is less than the trigger temperature set on the external thermostat, and will continue for a period of 30 minutes after
the temperature rises above the set trigger temperature.
www.poolcop.com
I have internal antifreeze protection which will
start the filtration if low temperatures are
This protects me in areas where running the pool all
year round is possible, and protects against short
periods of cold weather.
POOL DATA
POOL DATA menu throughout the year.
damage will be avoided under all circumstances, as this depends on many factors.
No responsibility will be accepted for damage caused due to freezing.
Technical Support "Hotline" +33 (0)4 90 09 54 26
detected.
menu (the default is ON).
CAUTION:
NOTE:
menu.
ON. This protects equipment in the pump and filter area
POOL DATA
P o o l C o p M a n u a l : V 3 1 E N
POOL DATA
menu. The filtration will run at all times that the
menu. The
ON in
