PoolCop Installer And User Manual page 14

P a g e | 1 4
2.4.2.3 Visit check list
The following check will help you to maintain PoolCop in good conditions and to optimize your visits.
Date: Firmware version:
Category
X X
X X
General
X X
X X
Leaks
X X
X X Valve rotation
X X Pressure
X X pH
X X pH Control
X Ionizer
X X Disinfection
X X Battery
X Electrodes ionizer
X Firmware
X Valve gasket
www.poolcop.com
Client:
Check power (red leds on PSU).
Check data: Temperature, Pressure, valve position, pH,
ORP, date/time.
Water data to check in the pool:
pH =
ORP =
TAC =
Start pump and check absence of leakage to waste, check
pressure.
Check no leak inside/outside.
If pool water level is ok do a backwash.
Check valve rotation (no abnormal noise).
Check filter cleanliness.
Stop the pump; check the zero pressure (static head).
If not correct, check/add oil in the piston.
Stop the pump, ask for pH reading.
If not ok check/calibrate sensor.
Set timers for immediate start.
Check pH injection, and Autochlor (if any)
If Acid depleted, check electrode in fresh acid.
Replace electrode or drum
After 2 min, check ionizer current.
If possible, leave the filtration run for 30 minutes and
check ORP disinfection dosing (chlorine/salt system).
Put valve in waste position (if possible, bypass otherwise).
Remove 220VAC power supply and check valve rotation
in safe position.
in not ok, check battery voltage (>11.5V).
When battery is disconnected, charging circuit voltage
should be > 13.5V.
Check electrodes wear, replace if needed.
Update firmware to latest version (if apply).
Unloose PoolCop from valve housing, check and grease
gasket. If damaged, replace the rotating part.
Technical Support "Hotline" +33 (0)4 90 09 54 26
P o o l C o p M a n u a l : V 3 1 E N
Item
Signature:
Checked Replaced
PCFR
