7.4

pH Sensor

Components

PH Sensor

Transport Cap
White Retaining Cap
Grip Washer
Black Compression Ring
White Compression Ring
O-Ring
Technical Specifications
Diameter
Length
Cable, length
Connector
pH Range
pH Accuracy
7.5

pH+ORP Sensors

Components
pH+ORP sensor
Transport Cap / Capuchon de transport
White Retaining Cap
Grip Washer
Black Compression Ring
White Compression Ring
O-Ring
Technical Specifications
Diameter
Length
Cable, length
Connector
pH Range
pH Accuracy
ORP Range
ORP Accuracy
7.6

Water Level Control

Components
Water level sensor.
Solenoid valve
PVC saddles 50mm
PVC saddles 63mm
90° PVC connector (20mm to 20mm)
Straight PVC connector 20mm
Non return valve, brass
Stop valve 15mm
Reducing connector (20mm to 15mm)
Technical Specifications
Output Sensor
Output valve
Temperature range
Cable length
Height
Width
Deep
www.poolcop.com
1
1
1
1
1
1
1
12 mm
14 cm
2 strands, 35cm
JST XHP-3
0 – 12
+/- 0.05
pH+ORP Pt
1
1
1
1
1
1
1
12 mm
14 cm
3 strands, 35cm
JST XHP-3
0 – 12
+/- 0.05
0 – 999 mV
+/- 5 mV
Waterline Kit
1 sensor
1
1
1
1
2
1
1
1
5 VDC, conforms Low Voltage Directive (LVD) 2006/95/EC
24 VAC
5°C - 45°C
20m
70mm
45mm
15mm
Technical Support "Hotline" +33 (0)4 90 09 54 26
pH+ORP Au
12 mm
14 cm
3 strands, 35cm
JST XHP-3
0 – 12
+/- 0.05
0 – 999 mV
+/- 5 mV
Skimmer Kit
1 sensor
1
1
1
1
2
1
1
1
24 VAC
5°C - 45°C
5m
25mm
30mm
45mm
P a g e | 1 0 1
1
1
1
1
1
1
1
Buffer Tank Kit
4 sensors
1
1
1
1
2
1
1
1
24 VAC
5°C - 45°C
5m
40mm
25mm
25mm
PCFR
