P o o l C o p M a n u a l : V 3 1 E N
3.5

Water Treatment

G
E N E R A L
PoolCop is compatible with all water treatments. There are no specific restrictions on use of any legally permitted swimming pool
water treatment with PoolCop. Follow all manufacturer recommended guidelines to ensure safety, correct dosing and equipment
life.Water treatments can be controlled using timers (slaved to filtration/circulation) or using water condition sensors and internal
algorithms.
There are three types of sensors available, the sensors have the same dimensions and fit the same housing in the PoolCop Main
Unit:
Treatment Option
pH Only
pH + liquid chlorine injection; chlorine or bromine tablets
pH + salt water system
Certain precautions must be taken PRIOR to installation of the sensor to ensure correct measurement and to
prevent the possibility of damage: Install and test an electrical earth bonding in accordance with local
regulations (in France this norm is NF C 15-100).Test the water for presence of metals (iron, zinc, copper)
I
N S T A L L I N G T H E
PoolCop has a housing in the Main Unit for the water condition sensor. Installation of the sensors is the identical.
Figure 22 – PoolCop
water analysis sensor
The water sensor connectors may have 3 or 4 pins (See Figure 25 – Sensor connexion (3 pins or 4 pins)). Make sure you have got the
correct sensor according to the following table:
PoolCop 3 pins
PoolCop 4 pins
If your PoolCop is provided with a 4 pins pH/ORP connector, you absolutly need to connect a 4 wires sensor
www.poolcop.com
N A
OT PPLICABLE TO
and use a metal sequestrate treatment in any case.
W C
A T E R O N D I T I O N
Figure 23 - Sensor and
Housing
3 wires sensor CO190x
Ok
Not compatible
Figure 26 – Sensor compatibility table
Technical Support "Hotline" +33 (0)4 90 09 54 26
P C J
OOL OP UNIOR
Sensor Required
pH Sensor kit
pH+ORP Pt Sensor kit
pH+ORP Au Sensor kit
WARNING:
S
E N S O R

Figure 24 - Sensor Housing plug

4 wires sensor SO490x
Compatible (adaptater provided)
Ok
WARNING:
SO4901, SO4902 ou SO4903.
P a g e | 2 9
Ref 3 wires Ref 4 wires
CO1901 SO4901
CO1902 SO4902
CO1903 SO4903
Figure 25 – Sensor connexion
(3 pins or 4 pins)
