Removing the Unit from a DIN Rail

Take the following steps to remove the unit from a DIN rail.
Step 1: Use your finger to pull the release tab on the lower part of the module.
Step 2: Press the release tab (item 1 in the figure) and then remove the CPU module from the DIN rail
(item 2 in the figure).
NOTE Disconnect all connections, including Ethernet, serial, and power cables, from the device before removing
the device from the DIN rail.
