Moxa Technologies ioThinx 4510 Series Quick Installation Manual
Hide thumbs
Also See for ioThinx 4510 Series:
- User manual (127 pages) ,
- Manual (10 pages) ,
- Quick installation manual (8 pages)
Related Manuals for Moxa Technologies ioThinx 4510 Series
Summary of Contents for Moxa Technologies ioThinx 4510 Series
- Page 1 4510 Series Quick Installation Guide Version 1.4, March 2024 Technical Support Contact Information www.moxa.com/support 2024 Moxa Inc. All rights reserved. P/N: 1802045101014 *1802045101014*...
-
Page 2: Package Checklist
The ioThinx 4510 is an advanced modular remote I/O device with a unique hardware and software design that makes it ideal for a variety of industrial data acquisition applications. Package Checklist • 1 x ioThinx 4510 Series product • 1 x quick installation guide (printed) • 2 x side cover plate... - Page 3 Connect your 12 to 48 VDC power source to the terminal block SP+ and SP- terminals on the ioThinx 4510. The ground connector of the system is on the back of the unit, which will connect to the DIN rail when the product is attached to it.
-
Page 4: Connecting To The Network
Connecting Field Power Wire Range: 12 to 16 AWG (ferrule diameter: 2.053 to 1.291 mm) Wire Strip Length: 10 mm The ioThinx 4510 can receive field power through a 12/24 VDC power input. Field power can be used to supply power for some I/O modules, such as digital input and analog output modules. - Page 5 Serial Communication The ioThinx 4510 is equipped with a 3-in-1 serial interface, which supports 1 RS-232 port, or 1 RS-422 port, or 2 RS-485 ports. Refer to the pin assignment table below to set up serial connections to the unit. RS-232 RS-422 RS-485...
- Page 6 Step 2: Push the unit toward the DIN rail until the mounting clip snaps in place. Installing a 45M Module on a DIN Rail Step 1: Align the 45M module side by side with the head/CPU module, making sure that the upper and lower rails are hooked together.
- Page 7 Step 2: Align the 45M module side by side with the head/CPU module and then push the 45M module until it touches the DIN rail. Next, apply more force until the module clips on to the DIN rail. NOTE After the module is firmly attached to the DIN rail, the module connections to the internal bus will be established.
- Page 8 Step 2: Push the top of the release tab to latch it, and then pull the module out. NOTE Electrical connections for the internal bus will be disconnected when removing the 45M module. WARNING Be sure the power is off before removing modules to avoid damaging the equipment.
-
Page 9: Horizontal Installation
Horizontal Installation Before installing the device, make sure there is enough space between the device and nearby items (walls and other devices/equipment) to ensure proper heat dissipation. To ensure that the device works properly, we suggest reserving the amount of space indicated in the adjacent figure. -
Page 10: System Configuration
System Configuration 1. Configuration via Web Console Main configuration of the unit is done through the web console. • Default IP Address: 192.168.127.254 • Subnet Mask: 255.255.255.0 NOTE Be sure to configure the host PC’s IP address to use the same subnet as the unit. -
Page 11: Specifications
Step 3: Go to the Software page to download the latest software for the product. Specifications Input Current System Power: 0.8 A @ 12 VDC Field Power: 2 A (max.) Input Voltage 12 to 48 VDC Field Power: 12/24 VDC Operating Temperature Standard Models: -20 to 60°C (-4 to 140°F) -
Page 12: Warning-Explosion Hazard
WARNING—EXPLOSION HAZARD Do not disconnect the equipment unless the power has been removed or the area is known to be nonhazardous. Substitution of any components may impair suitability for Class I, Division 2. WARNING The Debug port and Console port are FOR MAINTENANCE ONLY;...
