ioThinx 4510 Series

45MR-2606 (-T), 8 DIs, 8 DOs Registers

01: COIL STATUS
Parameter
doStatus
diCounterStatus
diCounterOverflowFlagClear
doPulseStatus
02: INPUT STATUS?
Parameter
diStatus
diMode
doMode
diCounterOverflowFlag
03: HOLDING REGISTER
Parameter
diCounterValue
doStatusAll
doPulseCount
doPulseOnWidth
doPulseOffWidth
doPulseStatusAll
diCounterStatusAll
diCounterOverflowFlagClearAll
04: INPUT REGISTER
Parameter
diStatusAll
diCounterOverflowFlagAll
diModeAll
doModeAll
Description
DO - status (0: OFF, 1: ON)
DI - Counter mode - status (0: Pause, 1: Run)
DI - Counter mode - clear overflow flag (1:
Clear)
DO - Pulse mode - status (0: Stop, 1: Start)
Description
DI - DI mode - status (0: OFF, 1: ON)
DI - mode (0: DI, 1: Counter)
DO - mode (0: DO, 1: Pulse)
DI - Counter mode - overflow flag (0: Normal,
1: Overflow)
Description
DI - Counter mode - value
DO - status (0: OFF, 1: ON)
DO - Pulse mode - count
DO - Pulse mode - ON width (unit: 500 us)
DO - Pulse mode - OFF width (unit: 500 us)
DO - Pulse mode - status (0: Stop, 1: Start)
DI - Counter mode - status (0: Pause, 1: Run)
DI - Counter mode - clear overflow flag (1:
Clear)
Description
DI - DI mode - status (0: OFF, 1: ON)
DI - Counter mode - overflow flag (0: Normal, 1:
Overflow)
DI - mode (0: DI, 1: Counter)
DO - mode (0: DO, 1: Pulse)
A-6
Appendix
Length Type
8 BOOL
2 BOOL
2 BOOL
2 BOOL
Length Type
8 BOOL
8 BOOL
8 BOOL
2 BOOL
Length Type
4 DWORD
1 WORD
4 DWORD
2 WORD
2 WORD
1 WORD
1 WORD
1 WORD
Length Type
1 WORD
1 WORD
1 WORD
1 WORD
