ioThinx 4510 Series

45MR-1601 (-T), 16 DIs Registers

01: COIL STATUS
Parameter
diCounterStatus
diCounterOverflowFlagClear
02: INPUT STATUS?
Parameter
diStatus
diMode
diCounterOverflowFlag
03: HOLDING REGISTER
Parameter
diCounterValue
diCounterStatusAll
diCounterOverflowFlagClearAll DI - Counter mode - clear overflow flag (1: Clear)
04: INPUT REGISTER
Parameter
diStatusAll
diCounterOverflowFlagAll
diModeAll

45MR-2404 (-T), 4 Relays Registers

01: COIL STATUS
Parameter
relayStatus
relayCurrentCountReset
03: HOLDING REGISTER
Parameter
relayStatusAll
04: INPUT REGISTER
Parameter
relayTotalCount
relayCurrentCount
Description
DI - Counter mode - status (0: Pause, 1: Run)
DI - Counter mode - clear overflow flag (1: Clear)
Description
DI - DI mode - status (0: OFF, 1: ON)
DI - mode (0: DI, 1: Counter)
DI - Counter mode - overflow flag (0: Normal, 1:
Overflow)
Description
DI - Counter mode - value
DI - Counter mode - status (0: Pause, 1: Run)
Description
DI - DI mode - status (0: OFF, 1: ON)
DI - Counter mode - overflow flag (0: Normal, 1:
Overflow)
DI - mode (0: DI, 1: Counter)
Description
Relay - Relay mode - status (0: OFF, 1: ON)
Relay - reset current count (1: Reset)
Description
Relay - Relay mode - status (0: OFF, 1: ON)
Description
Relay - total count
Relay - current count
A-4
Appendix
Length Type
4 BOOL
4 BOOL
Length Type
16 BOOL
16 BOOL
4 BOOL
Length Type
8 DWORD
1 WORD
1 WORD
Length Type
1 WORD
1 WORD
1 WORD
Length Type
4 BOOL
4 BOOL
Length Type
1 WORD
Length Type
8 DWORD
8 DWORD
