ioThinx 4510 Series

45MR-4420 (-T), 4 AOs Registers

03: HOLDING REGISTER
Parameter
aoValueRaw
aoValueScaled
04: INPUT REGISTER
Parameter
aoMode

45MR-6600 (-T), 6 RTDs Registers

01: COIL STATUS
Parameter
rtdResetMinValue
rtdResetMaxValue
03: HOLDING REGISTER
Parameter
rtdResetMinValueAll
rtdResetMaxValueAll
04: INPUT REGISTER
Parameter
rtdValueScaled
rtdValueScaledMin
rtdValueScaledMax
rtdType
rtdStatus
Description
AO - raw value
AO - scaled value
Description
AO - mode (0: disable, 1: 0-10 V, 2: 0-20 mA,
3: 4-20 mA, 4: ±10 V)
Description
RTD - reset minimum value (1: Reset)
RTD - reset maximum value (1: Reset)
Description
RTD - reset minimum value (1: Reset)
RTD - reset maximum value (1: Reset)
Description
RTD - scaled value
RTD - minimum scaled value
RTD - maximum scaled value
RTD - Type (0: PT50, 1: PT100, 2: PT200, 3:
PT500, 4: PT1000; 14: 310 Ohm, 15: 620 Ohm,
16: 1250 Ohm, 17: 2200 Ohm; 20: JPT100, 21:
JPT200, 22: JPT500, 23: JPT1000; 30: NI100,
31: NI200, 32: NI500, 33: NI1000, 34: NI120)
RTD - Status (0: normal, 1:burnout)
A-8
Appendix
Length Type
4 WORD
8 REAL
Length Type
4 WORD
Length Type
6 BOOL
6 BOOL
Length Type
1 WORD
1 WORD
Length Type
12 REAL
12 REAL
12 REAL
6 WORD
6 WORD
