ioThinx 4510 Series
04: INPUT REGISTER
Parameter
modbusRtuMasterDeviceStatus
modbusRtuMasterprofileErrorCode Modbus/RTU Master - profile error code
deviceName
deviceDate
deviceTime
deviceUpTime
firmwareVersion
firmwareBuildDate
serialNumber
lanMac
lanIp
systemError

45MR-1600 (-T), 16 DIs Registers

01: COIL STATUS
Parameter
diCounterStatus
diCounterOverflowFlagClear
02: INPUT STATUS
Parameter
diStatus
diMode
diCounterOverflowFlag
03: HOLDING REGISTER
Parameter
diCounterValue
diCounterStatusAll
diCounterOverflowFlagClearAll DI - Counter mode - clear overflow flag (1: Clear)
04: INPUT REGISTER
Parameter
diStatusAll
diCounterOverflowFlagAll
diModeAll
Description
Modbus/RTU Master - device status
device name
device date
e.g. 2016/06/28 -> 20160628
device local time
e.g. 15:48:25 -> 154825
unit: sec(s)
Each byte represents ASCII code. e.g. 1.2.3 --
> V1.2.3 , 11.13.12 -->V11.13.12
Each byte represents ASCII code. E.g.
16051718 --> Build16051718
Each byte represents ASCII code of serial
number English character : e.g.
TAGCB1100001
MAC address
IP address
System Error
Description
DI - Counter mode - status (0: Pause, 1: Run)
DI - Counter mode - clear overflow flag (1: Clear)
Description
DI - DI mode - status (0: OFF, 1: ON)
DI - mode (0: DI, 1: Counter)
DI - Counter mode - overflow flag (0: Normal, 1:
Overflow)
Description
DI - Counter mode - value
DI - Counter mode - status (0: Pause, 1: Run)
Description
DI - DI mode - status (0: OFF, 1: ON)
DI - Counter mode - overflow flag (0: Normal, 1:
Overflow)
DI - mode (0: DI, 1: Counter)
A-3
Appendix
Length Type
4 WORD
8 WORD
8 BYTE
2 DWORD
2 DWORD
2 DWORD
4 BYTE
4 BYTE
6 BYTE
4 BYTE
2 BYTE
1 WORD
Length Type
4 BOOL
4 BOOL
Length Type
16 BOOL
16 BOOL
4 BOOL
Length Type
8 DWORD
1 WORD
1 WORD
Length Type
1 WORD
1 WORD
1 WORD
