ioThinx 4510 Series
Topic
{deviceName}/read/{ioName}/aiValueScaledMax
{deviceName}/read/{ioName}/aoMode
{deviceName}/read/{ioName}/aoValueRaw
{deviceName}/read/{ioName}/aoValueScaled
{deviceName}/read/{ioName}/aoStatus
{deviceName}/read/{ioName}/rtdStatus
{deviceName}/read/{ioName}/rtdMode
{deviceName}/read/{ioName}/rtdValueScaled
{deviceName}/read/{ioName}/rtdValueScaledMin RTD - minimum scaled
{deviceName}/read/{ioName}/rtdValueScaledMa
x
{deviceName}/read/{ioName}/rtdResetMinValue
{deviceName}/read/{ioName}/rtdResetMaxValue
{deviceName}/read/{ioName}/tcStatus
{deviceName}/read/{ioName}/tcType
{deviceName}/read/{ioName}/tcValueScaled
{deviceName}/read/{ioName}/tcValueScaledMin
{deviceName}/read/{ioName}/tcValueScaledMax
{deviceName}/read/{ioName}/tcResetMinValue
{deviceName}/read/{ioName}/tcResetMaxValue
Description
AI - maximum scaled
value
AO - mode (0:
Disable, 1: 0-10 V, 2:
0-20mA, 3: 4-20 mA)
AO - raw value
AO - scaled value
AO – status (0:
Normal, 1: Fault)
RTD - Status (0:
normal, 1: burnout)
RTD - Type (0: PT50,
1: PT100, 2: PT200, 3:
PT500, 4: PT1000; 14:
310 Ohm, 15: 620
Ohm, 16: 1250 Ohm,
17: 2200 Ohm; 20:
JPT100, 21: JPT200,
22: JPT500, 23:
JPT1000; 30: NI100,
31: NI200, 32: NI500,
33: NI1000, 34:
NI120, 50: disable)
RTD - scaled value
value
RTD - maximum
scaled value
RTD - reset minimum
value (1: RESET)
RTD - reset maximum
value (1: RESET)
TC - Status (0:
normal, 1: burnout)
TC - Type (0: J Type,
1: K Type, 2: T Type,
3: E Type, 4: R Type,
5: S Type, 6: B Type,
7: N Type, 14:
±78.126 mV, 15:
±39.062 mV, 16:
±19.532 mV, 50:
disable)
TC - scaled value
TC - minimum scaled
value
TC - maximum scaled
value
TC - reset minimum
value (1: RESET)
TC - reset maximum
value (1: RESET)
A-15
Appendix
Category Trigger
attribute Interval
attribute Interval
attribute Interval
value both (interval)
value both
(OnChange)
value both
(OnChange)
attribute Interval
value both (interval)
attribute Interval
attribute Interval
attribute Interval
attribute Interval
value both
(OnChange)
attribute Interval
value both (interval)
attribute Interval
attribute Interval
attribute Interval
attribute Interval
