SYS T E M OV E R V I E W
2.2

Control elements

sMove controller
The connected ventilation units can be controlled in the following modes:
• Heat recovery
• Ventilation
MZ-Home controller
within the accommodation unit. For each zone, the operating mode and output level can be set
manually or via a 7-day timer.
The connected ventilation units can be controlled in the following modes:
• Heat recovery
• Ventilation
The sMove and MZ-Home controllers can be expanded with additional sensors.
An external interface allows the connection of a potential-free switching contact or integration
into an existing home automation system via an analogue input.
For detailed information see the separate operating instructions of the controller.
+
iV-Smart
10
The controllers from the sMove product range are electronic control
unit for controlling the iV-Smart
They are characterised by their timeless and slim design and a
simple touch-based operating concept.
The sMove controller is available in the s4 and s8 versions.
s4 is used to control up to four iV-Smart
s8 is used to control up to eight iV-Smart
Both versions are available in a flat and standard version: In contrast
to the flat version, in addition to pause mode, the standard version
provides the option to switch off the ventilation unit completely.
The MZ-Home controller is an electronic control unit for controlling
up to 16 iV-Smart
It is characterised by Clust-Air technology (multizone control),
simple installation, touch-based operation and its versatility.
The MZ-Home controller consists of a control unit and at least one
(optional up to four) Clust-Air module(s). Each Clust-Air module
can control up to four iV-Smart
within the accommodation unit. This allows the MZ-Home controller
to provide varied ventilation for up to four different areas (zones)
ventilation system • Installation instructions
+
ventilation units.
+
ventilation units.
+
• Pause function
• Off (only sMove standard version)
+
ventilation units.
+
ventilation units in different zones
• Dehumidification
• Off / Pause function
ventilation units.
