SYS T E M OV E R V I E W
2

System overview

The iV-Smart
and multi-family houses, hotels and guest houses, rooms in public facilities and work rooms in
office buildings. It is suitable for installation in new buildings as well as for retrofitting in existing
buildings. Installation is carried out in the exterior wall.
The ventilation unit iV-Smart
is installed, as well as an inner cover and an exterior closure.
The thermal accumulator insert contains the ceramic thermal accumulator and inVENTron.
Due to the flow-optimised design of inVENTron, the two guiding vanes with embedded Xenion
reversible fan, ensures efficient capacity utilisation and even flow through the thermal
accumulator.
The standard length of the wall sleeve is 495 mm. For thicker walls, there is the option of
ordering a wall sleeve with a length of 745 mm. Both versions can be trimmed on site.
It is controlled via one of the following inVENTer system controllers
• sMove s4
Components
• Inner cover inkl. dust filter of class G4
• Thermal accumulator insert
(thermal accumulator and inVENTron)
• Wall sleeve
• Exterior closure:
Models
• Standard version: iV-Smart
protection hood (white/grey/Nord/custom colour)
• Corner version: iV-Smart
lation layer and reveal grille (white/grey/Nord/custom colour)
Corner version is particularly suitable when subsequently fitting insulation or if a weather
protection hood cannot be fitted to the outside wall for structural or other reasons (e.g. listed
buildings). Due to the reveal grille in the window reveal the ventilation unit disappears subtly
into the external wall.
• Ohio version: Ventilation units iV-Smart+ with Ohio weather protection hood (grey)
It is designed as an solution for buildings with the special requirements of particullarly thin
exterior walls, e. g. if due to construction requirements no thermal insulation may be fitted.
The installation and operating instructions for the controller do not form part of this documentation and are supplied separately.
1)
+
iV-Smart
8
+
ventilation system is designed to ventilate living rooms and bedrooms in single-
+
comprises a wall sleeve into which a thermal accumulator insert
• sMove s8
+
ventilation units with driving rain proof Nova or Smart weather
+
ventilation units with flat duct for integration into the thermal insu-
ventilation system • Installation instructions
:
1)
• MZ-Home
• Pollen, micro and activated carbon filter
options available
• Sound and wind protection options
available as accessory
