Construction

D
21
20
Figure 13: Overview of iV-Smart
Components
A
Exterior closure: Ohio weather
protection hood
1 Metal sleeve
2 Attachment point protective grille (4 x)
3 Louvres of protective grille
4 Weather protection grille [protective grille]
5 Sealing tape
6 Neopor insert
7 Attachment points exterior wall (4 x)
8 Opening for wall sleeve
B
Wall sleeve
9 Wall sleeve R-D160
10 Recess for fan BUS (interior wall
side)
+
Ohio ventilation unit
C
16
14
15
17
18
19
+
Ohio ventilation unit
iV-Smart
I V- S M A R T+ O H I O V E N T I L AT I O N U N I T
B
12
10
11
13
C
Thermal accumulator insert
(thermal accumulator and inVENTron)
11 Thermal accumulator with insulation
12 Thermal accumulator handle
13 Standard guiding vane (broad)
14 Xenion reversible fan
15 Slim guiding vane
16 Guiding vane knob
17 BUS plug connection
D
Flair inner cover
18 Inner cover base plate
19 Dust filter
20 Inner cover panel
21 Spacer (4 x)
Pollen, micro and activated carbon filter options
1)
available
+
ventilation system
A
7
8
6
1
5
9
A
4
3
2)
