Position of wall opening
≥ 250
180
Ø
180
With Smart protective hood
Figure 5: Dimensioned drawing of wall opening iV-Smart
1 Wall opening: New building
(Simplex as an option)
2 Wall opening: Existing buildings
3 Position of protective hood (contour)
Minimum distance to adjacent components on the interior wall
1)
Minimum distance to adjacent components on the exterior wall:
2)
Inner cover
Figure 6: Dimensioned drawing of Flair inner cover V-233x233
1 Inner cover panel
2 Sound insulation (optional)
3 Holding plate IC V-233x233
4 Inner cover base plate
I V- S M A R T+ V E N T I L AT I O N U N I T
6
1
2
5
3
4
A
A
215
□
233
+
iV-Smart ventilation system
180
Ø
180
With Nova protective hood
+
(Interior view)
4 Window reveal
5 Door/window frame
6 Bottom edge of reveal
Observe insulation/shutters
3)
6
5
4
4
5 Spacer (4 x)
6 Interior wall attachment with Ø 6 mm,
min. 40 mm deep (4 x)
• Installation instructions
≥ 250
6
1
2
5
3
4
3)
A - A
