I V- S M A R T+ C O R N E R V E N T I L AT I O N U N I T
6 iV-Smart
6.1

Construction

D
24
23
Figure 7: Overview of iV-Smart
Components
A
Exterior closure:
Reveal grille and flat duct
1 Reveal grille
2 Louvres
3 Through hole (2 x)
4 Condensate drip
5 Drip rails
6 Flat duct sliding sleeve
7 Fastening elements reveal grille (2 x)
8 Corner flat duct:
9 Opening for wall sleeve
10 Sealing tape
11 Neopor insert
B
Wall sleeve
12 Wall sleeve R-D160
13 Recess for fan BUS
(interior wall side)
+
iV-Smart
28
+
Corner ventilation unit
C
15
19
17
18
20
21
22
+
Corner ventilation unit
ventilation system • Installation instructions
B
13
14
16
C
Thermal accumulator insert
(thermal accumulator and inVENTron)
14 Thermal accumulator with insulation
15 Thermal accumulator handle
16 Standard guiding vane (broad)
17 Xenion reversible fan
18 Slim guiding vane
19 Guiding vane knob
D
Flair inner cover
20 BUS plug connection
21 Inner cover base plate
22 Dust filter
23 Inner cover panel
24 Spacer (4 x)
Pollen, micro and activated carbon filter options
1)
available
A
9
10
11
8
6
12 5
2)
7
1
2
3
4
