U S E R A N D S A F E T Y I N S T R U C T I O N S
• NOTICE: Install the wall sleeve with a slope of 1 – 2° to the exterior wall in order to ensure
that occuring condensate may drain away.
• NOTICE: The ventilation unit must not be installed in areas in which direct contact with water
spray is possible.
• NOTICE: In order to prevent algae accumulation and a discolouration of the façade around
the weather protection hood observe all installation advices (apply all sealing tapes!). In
vulnerable areas, apply a biocidal/water repellant treatment to the plaster surface around the
weather protection hood, flat duct and the reveal grille before installing. Consult your planner!
• NOTICE: When installing components to (exterior) walls with insulation use insulation plugs
to ensure safe fastening. These are not part of the scope of supply, but are available as an
option.
• NOTICE: Exclusively use permanently elastic sealing compound for exterior/outdoor use to
seal the joints at the exterior closures (protective hoods Nova and Ohio).
• NOTICE: Your ventilation unit has scratch-sensitive plastic surfaces. Do not touch the inner
cover with oily and/or dirty hands. Avoid contact with sharp or pointed objects, e.g. rings.
Wiring/Electrical connection of the fan
• CAUTION: Electrical connection of the system may only be performed by qualified
personnel.
• NOTICE: Your ventilation unit operates with a safety extra low voltage (SELV) and an
operating voltage of 6 – 16 V DC. The ventilation unit must therefore not be connected
directly to the 230 V mains, but must always be connected via a controller.
• NOTICE: Exclusively lay cables without a plaster-resistant cable sheath inside an empty
conduit.
• The ventilation units must be synchronised when using multiple ventilation units controlled
via multiple controllers (see installation and operating instructions for the controller). All of the
controllers should be connected via a mains fuse in the building distributor.
If your equipment/system has a defect, contact your nearest distributor or our technical service.
Any kind of use other than the intended use will exclude all liability claims.
Improper use
Any use that is not mentioned in the intended use section, is considered to be improper.
Do not install the equipment in areas which...
• Contain (or may contain) strong oils or lubricants.
• Contain (or may contain) flammable gases, liquids or vapours.
• Contain (or may contain) extreme dusts.
• Are exposed to ambient temperatures below -20 °C and above 50 °C.
• Contains obstacles that hinder access to, or removal of, the unit's components.
+
