inVENTer iV-Smart+ User Manual page 44

I V- S M A R T+ O H I O V E N T I L AT I O N U N I T
Weather protection hood
5
6
7
Figure 17: Dimensioned drawing of Ohio protective hood
1 Attachment points for protective grille
2 Neopor insert
3 Attachment points exterior wall (4 x)
4 Metal sleeve
+
iV-Smart ventilation system
44
4
230
• Installation instructions
110
M4x0,7 (4x)
4
5
6
5 Protective grille
6 Louvres
7 Fastening screws for protective grille
(4 x)
227
210
1
2
6
Ø
3
163
