I V- S M A R T+ V E N T I L AT I O N U N I T
5 iV-Smart
5.1

Construction

D
19
18
Figure 1: Overview of iV-Smart
Components
A
Exterior closure: weather
protection hood
1 Nova-R protective hood base plate
2 Nova protective hood cover
3 Smart protective hood base plate
4 Fastening screws for cover (4 x)
5 Smart protective hood cover
6 Sealing tape
Wall sleeve
B
7 Wall sleeve R-D160
8 Recess for fan BUS (interior wall
side)
Choice between Smart (magnifier, figure 1, left) or Nova (magnifier, figure 1 right) protective hood
1)
Pollen, micro and activated carbon filter options available
2)
+
iV-Smart
16
+
ventilation unit
C
14
13
15
16
17
+
Standard ventilation unit
ventilation system • Installation instructions
8
10
9
A
11
12
5
C
Thermal accumulator insert
(thermal accumulator and inVENTron)
9 Thermal accumulator with insulation
10 Thermal accumulator handle
11 Standard guiding vane (broad)
12 Xenion reversible fan
13 Slim guiding vane
14 Guiding vane knob
15 BUS plug connection
D
Flair inner cover
16 Inner cover base plate
17 Dust filter
18 Inner cover panel
19 Spacer (4 x)
B
6
7
3
2
4
Smart
1)
2)
A
1
Nova
1)
