I V- S M A R T+ C O R N E R V E N T I L AT I O N U N I T
Sectional drawing
G
Figure 8: Sectional drawing iV-Smart
A Plaster
B Masonry
C Window frame
D Window casement
1 Reveal grille
2 Flat duct sliding sleeve
3 Corner flat duct
4 Wall bracket (2x)
5 Joint tape
6 Sealing tape
7 Thermal accumulator
Insulation on flat duct must be at least 10 mm.
1)
Use flat duct Corner 400 if (y + z) is at least 265 mm / is max. 285 mm.
2)
Use flat duct Corner 500 if (y + z) is at least 365 mm / is max. 385 mm.
3)
+
iV-Smart ventilation system
30
233
11
10
9
8
7
6
5
160
Ø
4
F
+
Corner ventilation unit (plan view)
2), 3)
• Installation instructions
Installation length of the flat duct:
L = ( y + z
y ≥ 250
A B
3
5
E Render of reveal
F Render
G Insulation
1)
8 inVENTron:
Xenion reversible fan embedded in
guiding vanes
9 Wall sleeve
10 Inner cover base plate
11 Inner cover panel
) +120
15 ≤ z ≤ 35
C D
E
1
