Wall opening
Figure 16: Dimensioned drawing of wall opening iV-Smart
1 Wall opening: New buildings
(Simplex as an option)
2 Wall opening: Existing buildings
3 Position of protective hood (contour)
Minimum distance to adjacent components on the interior wall
1)
Observe insulation/shutters on exterior wall
2)
Inner cover
Figure 15: Dimensioned drawing of Flair inner cover V-233x233
1 Inner cover panel
2 Sound insulation (optional)
3 Holding plate IC V-233x233
4 Inner cover base plate
I V- S M A R T+ O H I O V E N T I L AT I O N U N I T
≥ 250
180
Ø
180
A
A
215
□
233
+
iV-Smart ventilation system
6
1
2
5
3
4
+
Ohio (Interior view)
4 Window reveal
5 Door/window frame
6 Bottom edge of reveal
6
5
4
4
5 Spacer (4 x)
6 Interior wall attachment with Ø 6 mm,
min. 40 mm deep (4 x)
• Installation instructions
2)
A - A
1
2
3
61
