13. Appendix

13.1 Parameter Defaults

If you require assistance from your supplier or a service technician, please note all parameter settings in the table
below.
1 Primary Motor Settings
Motor Full Load Current
1A
Locked Rotor Time
1B
Locked Rotor Current
1C
1D Motor Service Factor
2 Start/Stop Modes-1
Start Mode
2A
Start Ramp Time
2B
Initial Current
2C
Current Limit
2D
Reserved
2E
Kickstart Time
2F
Kickstart Level
2G
Stop Mode
2H
2I Stop Time
3 Auto-Start/Stop
Reserved
3A
Reserved
3B
Auto-Stop Type
3C
Auto-Stop Time
3D
4 Protection Settings
Excess Start Time
4A
Excess Start Time-2
4B
4C Undercurrent
4D Undercurrent Delay
Instantaneous Overcurrent
4E
Instantaneous Overcurrent Delay
4F
Phase Sequence
4G
Current Imbalance
4H
Current Imbalance Delay
4I
Frequency Check
4J
Frequency Variation
4K
Frequency Delay
4L
4M Restart Delay
Motor Temperature Check
4N
Ground Fault Level
4O
Ground Fault Delay
4P
Undervoltage
4Q
Undervoltage Delay
4R
Overvoltage
4S
Overvoltage Delay
4T
4U Instantaneous Overcurrent S2
72
| MVE User Manual (710-17074-00H)
User Set 1 User Set 2 Default Value
100 A
00m:10s
600% FLC
105%
Constant Current
00m:01s
400% FLC
400% FLC
0 ms
500% FLC
Coast To Stop
00m:00s
Off
00h:01m
00m:20s
00m:20s
20% FLC
00m:05s
400% FLC
00m:00s
Positive Only
30%
00m:05s
Run
±5 Hz
00m:05s
30m:00s
Do Not Check
1 A
00m:03s
100 V
00m:05s
7200 V
00m:05s
4400 A
